Lenovo Intel Xeon Silver 4110
Model Intel Xeon Silver 4110Part no. 4XG7A07263EAN 8894884590014
47 specifications Checked yesterday
- ProcessorIntel Xeon Silver
- Maximum internal memory supported by processor768 GB
- On-board graphics cardNo
- Market segmentServer
- Intel Trusted Execution TechnologyYes
- Tcase77 °C
Overview
- Processor
- Intel Xeon Silver
- Maximum internal memory supported by processor
- 768 GB
- On-board graphics card
- No
- Market segment
- Server
- Intel Trusted Execution Technology
- Yes
- Tcase
- 77 °C
- Brand
- Lenovo
- Category
- CPU
- Model
- Intel Xeon Silver 4110
- Part numbers
- 4XG7A07263, 7XG7A05531, 7XG7A05575, 4XG7A07195, 4XG7A07203, 4XG7A07685 +3 more
- EAN / UPC
- 8894884590014, 889488433889, 4058154229125, 889488434282 +9 more
- Also known as
- Lenovo Intel Xeon Silver 4110 processor 2.1 GHz 11 MB L3
Specifications
47 specifications in 9 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel Xeon Silver |
| Processor generation | 1st Generation Intel® Xeon® Scalable |
| Processor model | 4110 |
| Processor base frequency | 2.1 GHz |
| Processor cores | 8 |
| Processor socket | LGA 3647 (Socket P) |
| Processor lithography | 14 nm |
| Cooler included | Yes |
| Component for | Server/workstation |
| Processor series | Intel® Xeon® Scalable |
| Processor threads | 16 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3 GHz |
| Processor cache | 11 MB |
| Processor cache type | L3 |
| Thermal Design Power (TDP) | 85 W |
| Stepping | U0 |
| Processor codename | Skylake |
| Processor ARK ID | 123547 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 768 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2400 MHz |
| Memory channels | Hexa-channel |
| ECC | Yes |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
Features
| Specification | Value |
|---|---|
| Market segment | Server |
| Maximum number of PCI Express lanes | 48 |
| PCI Express slots version | 3.0 |
| Supported instruction sets | AVX, AVX 2.0, AVX-512, SSE4.2 |
| Embedded options available | Yes |
Processor special features
| Specification | Value |
|---|---|
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Conflict-Free processor | Yes |
| Intel 64 | Yes |
| Intel TSX-NI | Yes |
| Intel Turbo Boost Max Technology 3.0 | No |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel® Optane™ Memory Ready | No |
| Intel® vPro™ Platform Eligibility | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tcase | 77 °C |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 85423119 |
Technical details
| Specification | Value |
|---|---|
| Launch date | Q3'17 |
| Status | Launched |
Weight & dimensions
| Specification | Value |
|---|---|
| Processor package size | 76 x 56.5 mm |
