Lenovo Intel Xeon E5-2623v4
Model Intel Xeon E5-2623v4Part no. 4XG0M66723EAN 190940727270
69 specifications Checked 2 days ago
- ProcessorIntel® Xeon® E5 v4
- GraphicsNot available
- Maximum internal memory supported by processor1.53 TB
- Discrete graphics cardNo
- Execute Disable BitYes
- Tcase73 °C
Overview
- Processor
- Intel® Xeon® E5 v4
- Graphics
- Not available
- Maximum internal memory supported by processor
- 1.53 TB
- Discrete graphics card
- No
- Execute Disable Bit
- Yes
- Tcase
- 73 °C
- Brand
- Lenovo
- Category
- CPU
- Model
- Intel Xeon E5-2623v4
- Part number
- 4XG0M66723
- EAN / UPC
- 190940727270
- Also known as
- Lenovo Xeon Intel E5-2623v4 processor 2.6 GHz 10 MB Smart Cache Tray
Specifications
69 specifications in 7 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Xeon® E5 v4 |
| Processor model | E5-2623V4 |
| Processor base frequency | 2.6 GHz |
| Processor cores | 4 |
| Processor socket | LGA 2011-v3 |
| Processor lithography | 14 nm |
| Package type | Tray |
| Cooler included | No |
| Component for | Server/workstation |
| Processor series | Intel Xeon E5-2600 v4 |
| Processor threads | 8 |
| System bus rate | 8 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.2 GHz |
| Processor cache | 10 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 85 W |
| VID Voltage Range | 0 - 0 V |
| Stepping | R0 |
| Bus type | QPI |
| Number of QPI links | 2 |
| Memory bandwidth supported by processor (max) | 68.3 GB/s |
| Processor codename | Broadwell |
| Processor code | SR2PJ |
| Processor ARK ID | 92980 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 1.53 TB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 1600,1866,2133 MHz |
| Memory channels | Quad-channel |
| ECC | Yes |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | No |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Server |
| Maximum number of PCI Express lanes | 40 |
| PCI Express slots version | 3.0 |
| Supported instruction sets | AVX 2.0 |
| CPU configuration (max) | 2 |
| Embedded options available | No |
| Physical Address Extension (PAE) | 46 bit |
| Physical Address Extension (PAE) | Yes |
| Scalability | 2S |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Flex Memory Access | No |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | No |
| Intel® Turbo Boost Technology | 2.0 |
| Conflict-Free processor | Yes |
| Intel 64 | Yes |
| Intel Demand Based Switching | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Identity Protection Technology version | 0.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel TSX-NI | Yes |
| Intel TSX-NI version | 1.00 |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® OS Guard | Yes |
| Intel® Secure Key | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tcase | 73 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Processor package size | 45 x 52.5 mm |
