Lenovo Inte Xeon L5609
Model Inte Xeon L5609Part no. 69Y4746
17 specifications Checked 3 days ago
- ProcessorIntel® Xeon® 5000 Sequence
- Maximum operating temperature63.1 °C
Overview
- Processor
- Intel® Xeon® 5000 Sequence
- Maximum operating temperature
- 63.1 °C
- Brand
- Lenovo
- Category
- CPU
- Model
- Inte Xeon L5609
- Part numbers
- 69Y4746, 81Y6713
- Also known as
- Lenovo Inte Xeon L5609 processor 1.86 GHz 12 MB L3 Tray
Specifications
17 specifications in 2 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Xeon® 5000 Sequence |
| Processor model | L5609 |
| Processor base frequency | 1.86 GHz |
| Processor cores | 4 |
| Processor socket | Socket B (LGA 1366) |
| Processor lithography | 32 nm |
| Package type | Tray |
| Processor threads | 4 |
| System bus rate | 4.8 GT/s |
| Processor operating modes | 64-bit |
| Processor cache | 12 MB |
| Processor cache type | L3 |
| Thermal Design Power (TDP) | 40 W |
| VID Voltage Range | 0.750 - 1.350 V |
| Stepping | B1 |
| Processor code | SLBVJ |
Operational conditions
| Specification | Value |
|---|---|
| Maximum operating temperature | 63.1 °C |
