INTEL XEON E7-4850 v3
Model INTEL XEON E7-4850 v3Part no. SR221
84 specifications Checked today
- ProcessorIntel® Xeon® E7 v3
- GraphicsNot available
- TypeProcessor
- Processor manufacturerIntel
- Maximum internal memory supported by processor1.53 TB
- Discrete graphics cardNo
Overview
- Processor
- Intel® Xeon® E7 v3
- Graphics
- Not available
- Type
- Processor
- Processor manufacturer
- Intel
- Maximum internal memory supported by processor
- 1.53 TB
- Discrete graphics card
- No
- Brand
- HP
- Category
- CPU
- Model
- INTEL XEON E7-4850 v3
- Part number
- SR221
- Also known as
- HP Xeon INTEL E7-4850 v3 processor 2.2 GHz 35 MB Last Level Cache Tray
Specifications
84 specifications in 10 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® E7 v3 |
| Processor model | E7-4850V3 |
| Processor base frequency | 2.2 GHz |
| Processor cores | 14 |
| Processor socket | LGA 2011 (Socket R) |
| Processor lithography | 22 nm |
| Package type | Tray |
| Component for | Server/workstation |
| Processor series | Intel Xeon E7-4800 v3 |
| Processor threads | 28 |
| System bus rate | 8 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 2.8 GHz |
| Processor cache | 35 MB |
| Processor cache type | Last Level Cache |
| Thermal Design Power (TDP) | 115 W |
| Stepping | E0 |
| Bus type | QPI |
| Number of QPI links | 3 |
| Memory bandwidth supported by processor (max) | 102 GB/s |
| Processor codename | Haswell |
| Processor code | SR221 |
| Processor ARK ID | 84679 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 1.53 TB |
| Memory types supported by processor | DDR4-SDRAM, DDR3-SDRAM |
| Memory clock speeds supported by processor | 1333,1600,1800,1066 MHz |
| Memory channels | Quad-channel |
| ECC | Yes |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | No |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Server |
| Maximum number of PCI Express lanes | 32 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | x4, x8, x16 |
| Supported instruction sets | AVX 2.0 |
| CPU configuration (max) | 4 |
| Embedded options available | No |
| PCI Express CEM revision | 3.0 |
| Physical Address Extension (PAE) | 46 bit |
| Physical Address Extension (PAE) | Yes |
| Scalability | S4S |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Conflict-Free processor | Yes |
| Intel 64 | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Instruction Replay Technology | No |
| Intel Instruction Replay Technology version | 0.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel TSX-NI | Yes |
| Intel TSX-NI version | 1.00 |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® OS Guard | Yes |
| Intel® Secure Key | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tcase | 70 °C |
Technical details
| Specification | Value |
|---|---|
| Processor cache | 35840 KB |
| Product type | Processor |
| Born on date | Q2'15 |
| Bus bandwidth | 8 |
| Bus speed | 8 GT/s |
| Bus type units | GT/s |
| Last change | 63903513 |
| Launch date | Q2'15 |
| Maximum memory | 1.53 TB |
| Processor brand name | Intel Xeon v2 |
| Product family | Intel Xeon Processor E7 v3 Family |
| Product name | Intel Xeon E7-4850 v3 (35M Cache, 2.20 GHz) |
| Status | Launched |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 8542310001 |
Weight & dimensions
| Specification | Value |
|---|---|
| Processor package size | 52 x 45 mm |
Other features
| Specification | Value |
|---|---|
| Intel® Virtualization Technology (Intel® VT) | VT-x, VT-d |
| Cache memory | 35 MB |
| Maximum internal memory | 1572864 MB |
