HP Intel Xeon E5430
Model Intel Xeon E5430Part no. 464887-B21-RFBEAN 5711783553038
37 specifications Checked 6 days ago
- ProcessorIntel® Xeon® 5000 Sequence
- Weight1.58 kg
- On-board graphics cardNo
- Execute Disable BitYes
- Tcase67 °C
Overview
- Processor
- Intel® Xeon® 5000 Sequence
- Weight
- 1.58 kg
- On-board graphics card
- No
- Execute Disable Bit
- Yes
- Tcase
- 67 °C
- Brand
- HP
- Category
- CPU
- Model
- Intel Xeon E5430
- Part numbers
- 464887-B21-RFB, 464887-B21, 466656-B21, 462781-001, 466656-B21-RFB
- EAN / UPC
- 5711783553038, 883585667468, 4054317525967, 7330381898457 +5 more
- Also known as
- HP Intel Xeon E5430 processor 2.66 GHz 12 MB L2
Specifications
37 specifications in 7 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Xeon® 5000 Sequence |
| Processor model | E5430 |
| Processor base frequency | 2.66 GHz |
| Processor cores | 4 |
| Processor socket | LGA 771 (Socket J) |
| Processor lithography | 45 nm |
| Component for | Server/workstation |
| Processor threads | 4 |
| Processor operating modes | 64-bit |
| Processor cache | 12 MB |
| Processor cache type | L2 |
| L2 cache speed | 2.66 GHz |
| Processor front side bus | 1333 MHz |
| Thermal Design Power (TDP) | 80 W |
| VID Voltage Range | 0.85 - 1.35 V |
| Compatible chipsets | Intel® 5000P, Intel® 5000V, Intel® 5000X, Intel® 5100, Intel® 5400 |
| FSB Parity | Yes |
| Stepping | E0 |
| CPU multiplier (bus/core ratio) | 8 |
| Processor system type | DP |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Server |
| Number of Processing Die Transistors | 820 M |
| Processing Die size | 214 mm² |
| Embedded options available | No |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Demand Based Switching | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tcase | 67 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 1.58 kg |
| Processor package size | 37.5 mm |
Other features
| Specification | Value |
|---|---|
| Intel® Virtualization Technology (Intel® VT) | VT-x |
| Dimensions (WxDxH) | 152.4 x 155.7 x 171.4 mm |
