HP Intel Xeon E5240
Model Intel Xeon E5240Part no. 488545-001EAN 4054842489352
29 specifications Checked 2 days ago
- ProcessorIntel® Xeon® 5000 Sequence
- On-board graphics cardNo
- Execute Disable BitYes
- Tcase66 °C
Overview
- Processor
- Intel® Xeon® 5000 Sequence
- On-board graphics card
- No
- Execute Disable Bit
- Yes
- Tcase
- 66 °C
- Brand
- HP
- Category
- CPU
- Model
- Intel Xeon E5240
- Part number
- 488545-001
- EAN / UPC
- 4054842489352
- Also known as
- HP Intel Xeon E5240 processor 3 GHz 6 MB L2
Specifications
29 specifications in 6 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Xeon® 5000 Sequence |
| Processor model | E5240 |
| Processor base frequency | 3 GHz |
| Processor cores | 2 |
| Processor socket | LGA 771 (Socket J) |
| Processor lithography | 45 nm |
| Component for | Server/workstation |
| Processor operating modes | 64-bit |
| Processor cache | 6 MB |
| Processor cache type | L2 |
| Processor front side bus | 1333 MHz |
| Thermal Design Power (TDP) | 65 W |
| VID Voltage Range | 0.85 - 1.35 V |
| FSB Parity | No |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | No |
| Market segment | Server |
| Number of Processing Die Transistors | 410 M |
| Processing Die size | 107 mm² |
| Embedded options available | Yes |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Turbo Boost Technology | No |
| Intel Demand Based Switching | No |
| Intel Virtualization Technology (VT-x) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tcase | 66 °C |
Other features
| Specification | Value |
|---|---|
| Intel® Virtualization Technology (Intel® VT) | VT-x |
