HP Intel Xeon E5-1680 v4

HP Intel Xeon E5-1680 v4

Model Intel Xeon E5-1680 v4Part no. 864637-001

54 specifications Checked 2 days ago
  • ProcessorIntel® Xeon® E5 v4
  • Maximum internal memory supported by processor1.54 TB
  • On-board graphics cardNo
  • Execute Disable BitYes
  • Tcase70 °C
See all specifications

Overview

Processor
Intel® Xeon® E5 v4
Maximum internal memory supported by processor
1.54 TB
On-board graphics card
No
Execute Disable Bit
Yes
Tcase
70 °C
Brand
HP
Category
CPU
Model
Intel Xeon E5-1680 v4
Part number
864637-001
Also known as
HP Intel Xeon E5-1680 v4 processor 3.4 GHz 20 MB L3

Specifications

54 specifications in 6 groups

Processor

Processor familyIntel® Xeon® E5 v4
Processor modelE5-1680V4
Processor base frequency3.4 GHz
Processor cores8
Processor socketLGA 2011-v3
Processor lithography14 nm
Component forServer/workstation
Processor seriesIntel Xeon E5-1600 v4
Processor threads16
System bus rate0 GT/s
Processor operating modes64-bit
Processor boost frequency4 GHz
Processor cache20 MB
Processor cache typeL3
Thermal Design Power (TDP)140 W
Bus typeQPI
Number of QPI links0
Memory bandwidth supported by processor (max)76.8 GB/s

Memory

Maximum internal memory supported by processor1.54 TB
Memory types supported by processorDDR4-SDRAM
Memory clock speeds supported by processor1600,1866,2133,2400 MHz
Memory channelsQuad-channel
ECCYes

Graphics

On-board graphics cardNo

Features

Execute Disable BitYes
Idle StatesYes
Thermal Monitoring TechnologiesYes
Market segmentServer
Maximum number of PCI Express lanes40
PCI Express slots version3.0
Supported instruction setsAVX 2.0
CPU configuration (max)1
Embedded options availableNo
Physical Address Extension (PAE)46 bit
Physical Address Extension (PAE)Yes
Scalability1S

Processor special features

Enhanced Intel SpeedStep TechnologyYes
Intel Flex Memory AccessNo
Intel Trusted Execution TechnologyYes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Identity Protection Technology (Intel® IPT)Yes
Intel® Turbo Boost Technology2.0
Conflict-Free processorYes
Intel 64Yes
Intel Demand Based SwitchingYes
Intel TSX-NIYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® OS GuardYes
Intel® Secure KeyYes
Intel® vPro™ Platform EligibilityYes

Operational conditions

Tcase70 °C
