HP Intel Xeon 7020
Model Intel Xeon 7020Part no. 399752-001
35 specifications Checked 2 days ago
- ProcessorIntel® Xeon® 7000 Sequence
- ECCNo
- Execute Disable BitYes
- Tcase76 °C
Overview
- Processor
- Intel® Xeon® 7000 Sequence
- ECC
- No
- Execute Disable Bit
- Yes
- Tcase
- 76 °C
- Brand
- HP
- Category
- CPU
- Model
- Intel Xeon 7020
- Part number
- 399752-001
- Also known as
- HP Intel Xeon 7020 processor 2.66 GHz 2 MB L2
Specifications
35 specifications in 7 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Xeon® 7000 Sequence |
| Processor model | 7020 |
| Processor base frequency | 2.66 GHz |
| Processor cores | 2 |
| Processor socket | Socket 604 (mPGA604) |
| Processor lithography | 90 nm |
| Component for | Server/workstation |
| Processor series | Intel Xeon 7000 Series |
| Processor operating modes | 64-bit |
| Processor cache | 2 MB |
| Processor cache type | L2 |
| Processor front side bus | 667 MHz |
| Thermal Design Power (TDP) | 165 W |
| VID Voltage Range | 1.2625 - 1.4125 V |
| FSB Parity | Yes |
| Stepping | A0 |
Memory
| Specification | Value |
|---|---|
| ECC | No |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Market segment | Server |
| Number of Processing Die Transistors | 230 M |
| Processing Die size | 206 mm² |
| Embedded options available | No |
| Physical Address Extension (PAE) | 32 bit |
| Physical Address Extension (PAE) | Yes |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | No |
| Intel 64 | Yes |
| Intel Demand Based Switching | No |
| Intel Virtualization Technology (VT-x) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tcase | 76 °C |
Other features
| Specification | Value |
|---|---|
| Compatibility | ProLiant DL580 G3 |
