Intel Core i9-11900F

Model Intel Core i9-11900FPart no. 28A65AV

69 specifications Checked today

Overview

Brand: HP
Category: CPU
Model: Intel Core i9-11900F
Part number: 28A65AV
Also known as: HP Intel Core i9-11900F processor 2.5 GHz 16 MB Smart Cache Box

69 specifications in 7 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i9
Processor generation	11th gen Intel® Core™ i9
Processor model	i9-11900F
Processor base frequency	2.5 GHz
Processor cores	8
Processor socket	LGA 1200 (Socket H5)
Processor lithography	14 nm
Package type	Box
Processor threads	16
System bus rate	8 GT/s
Processor operating modes	64-bit
Processor boost frequency	5.2 GHz
Processor cache	16 MB
Processor cache type	Smart Cache
Thermal Design Power (TDP)	65 W
Memory bandwidth supported by processor (max)	50 GB/s
Processor ARK ID	212254

Specification	Value
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	3200 MHz
Memory channels	Dual-channel
ECC	No
Memory bandwidth (max)	50 GB/s

Specification	Value
Discrete graphics card	No
On-board graphics card	No
On-board graphics card model	Not available
Discrete graphics card model	Not available

Specification	Value
Execute Disable Bit	Yes
Idle States	Yes
Thermal Monitoring Technologies	Yes
Market segment	Desktop
Use conditions	PC/Client/Tablet
Maximum number of PCI Express lanes	20
PCI Express slots version	4.0
PCI Express configurations	1x16+1x4, 2x8+1x4, 1x8+3x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0, AVX-512
CPU configuration (max)	1
Embedded options available	No
Scalability	1S
Export Control Classification Number (ECCN)	5A992CN3
Commodity Classification Automated Tracking System (CCATS)	G167599

Specification	Value
Enhanced Intel SpeedStep Technology	Yes
Intel Trusted Execution Technology	No
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® Turbo Boost Technology	2.0
Intel® Thermal Velocity Boost	Yes
Intel® Turbo Boost Max Technology 3.0 frequency	5.1 GHz
Intel® Turbo Boost Technology 2.0 frequency	5 GHz
Intel® Gaussian & Neural Accelerator (Intel® GNA) 2.0	Yes
Intel® Thermal Velocity Boost Temperature	70 °C
Intel® Thermal Velocity Boost Frequency	5.2 GHz
Intel 64	Yes
Intel Software Guard Extensions (Intel SGX)	No
Intel Stable Image Platform Program (SIPP)	No
Intel Turbo Boost Max Technology 3.0	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® Boot Guard	Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU	Yes
Intel® OS Guard	Yes
Intel® Optane™ Memory Ready	Yes
Intel® Secure Key	Yes
Intel® vPro™ Platform Eligibility	No

Specification	Value
Tjunction	100 °C

Specification	Value
Harmonized System (HS) code	85423119
