Intel Core i9-10900X X-series
Model Intel Core i9-10900X X-seriesPart no. 8EC16AV
49 specifications Checked today
- ProcessorIntel® Core™ i9 X-series
- GraphicsNot available
- Processor manufacturerIntel
- Maximum internal memory supported by processor256 GB
- Discrete graphics cardNo
- Execute Disable BitYes
Overview
- Processor
- Intel® Core™ i9 X-series
- Graphics
- Not available
- Processor manufacturer
- Intel
- Maximum internal memory supported by processor
- 256 GB
- Discrete graphics card
- No
- Execute Disable Bit
- Yes
- Brand
- HP
- Category
- CPU
- Model
- Intel Core i9-10900X X-series
- Part number
- 8EC16AV
- Also known as
- HP Intel Core i9-10900X X-series processor 3.7 GHz 19.25 MB Smart Cache
Specifications
49 specifications in 6 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i9 X-series |
| Processor generation | 10th gen Intel® Core™ i9 |
| Processor model | i9-10900X |
| Processor base frequency | 3.7 GHz |
| Processor cores | 10 |
| Processor socket | LGA 2066 (Socket R4) |
| Processor lithography | 14 nm |
| Component for | PC |
| Processor threads | 20 |
| System bus rate | 8 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 4.5 GHz |
| Processor cache | 19.25 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 165 W |
| Memory bandwidth supported by processor (max) | 94 GB/s |
| Processor codename | Cascade Lake |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 256 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2933 MHz |
| Memory channels | Quad-channel |
| ECC | No |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | No |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Market segment | Desktop |
| Maximum number of PCI Express lanes | 48 |
| PCI Express slots version | 3.0 |
| Supported instruction sets | AVX 2.0, AVX-512, SSE4.1, SSE4.2 |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| PCI Express CEM revision | 3.0 |
| Scalability | 1S |
| Thermal solution specification | PCG 2017X |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel 64 | Yes |
| Intel Turbo Boost Max Technology 3.0 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Optane™ Memory Ready | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tjunction | 94 °C |
