HP Intel Core i5-680
Model Intel Core i5-680Part no. 617831-001EAN 4054842508589
52 specifications Checked 12 days ago
- ProcessorIntel® Core™ i5
- Maximum internal memory supported by processor16 GB
- On-board graphics cardYes
- Tcase72.6 °C
Overview
- Processor
- Intel® Core™ i5
- Maximum internal memory supported by processor
- 16 GB
- On-board graphics card
- Yes
- Tcase
- 72.6 °C
- Brand
- HP
- Category
- CPU
- Model
- Intel Core i5-680
- Part numbers
- 617831-001, BQ364AV, WT570AV, WT567AV
- EAN / UPC
- 4054842508589
- Also known as
- HP Intel Core i5-680 processor 3.6 GHz 4 MB L3 Tray
Specifications
52 specifications in 7 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Core™ i5 |
| Processor generation | Intel® Core™ i5 |
| Processor model | i5-680 |
| Processor base frequency | 3.6 GHz |
| Processor cores | 2 |
| Processor socket | LGA 1156 (Socket H) |
| Processor lithography | 32 nm |
| Package type | Tray |
| Processor threads | 4 |
| System bus rate | 2.5 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.86 GHz |
| Processor cache | 4 MB |
| Processor cache type | L3 |
| Thermal Design Power (TDP) | 73 W |
| Stepping | K0 |
| Memory bandwidth supported by processor (max) | 21 GB/s |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 16 GB |
| Memory types supported by processor | DDR3-SDRAM |
| Memory clock speeds supported by processor | 1066,1333 MHz |
| Memory channels | Dual-channel |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card model | Intel® HD Graphics |
| On-board graphics card base frequency | 733 MHz |
| Number of displays supported (on-board graphics) | 2 |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | No |
| Maximum number of PCI Express lanes | 16 |
| PCI Express slots version | 2.0 |
| PCI Express configurations | 1x16, 2x8 |
| Number of Processing Die Transistors | 382 M |
| Processing Die size | 81 mm² |
| Number of Graphics & IMC Die Transistors | 177 M |
| Graphics & IMC Die Size | 114 mm² |
| Supported instruction sets | SSE4.2 |
| Embedded options available | No |
| Graphics & IMC lithography | 45 nm |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel FDI Technology | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | Yes |
| Intel Demand Based Switching | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tcase | 72.6 °C |
Other features
| Specification | Value |
|---|---|
| Intel® Virtualization Technology (Intel® VT) | VT-d, VT-x |
