HP Intel Core i5-480M
Model Intel Core i5-480MPart no. 634693-001EAN 4054842512067
54 specifications Checked 12 days ago
- ProcessorIntel® Core™ i5
- Maximum internal memory supported by processor8 GB
- On-board graphics cardYes
- Tjunction105 °C
Overview
- Processor
- Intel® Core™ i5
- Maximum internal memory supported by processor
- 8 GB
- On-board graphics card
- Yes
- Tjunction
- 105 °C
- Brand
- HP
- Category
- CPU
- Model
- Intel Core i5-480M
- Part numbers
- 634693-001, LD526AV, LD790AV, XW548AV
- EAN / UPC
- 4054842512067
- Also known as
- HP Intel Core i5-480M processor 2.66 GHz 3 MB L3 Tray
Specifications
54 specifications in 7 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Core™ i5 |
| Processor generation | Intel® Core™ i5 |
| Processor model | i5-480M |
| Processor base frequency | 2.66 GHz |
| Processor cores | 2 |
| Processor lithography | 32 nm |
| Package type | Tray |
| Processor threads | 4 |
| System bus rate | 2.5 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 2.933 GHz |
| Processor cache | 3 MB |
| Processor cache type | L3 |
| Thermal Design Power (TDP) | 35 W |
| Stepping | K0 |
| Memory bandwidth supported by processor (max) | 17.1 GB/s |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 8 GB |
| Memory types supported by processor | DDR3-SDRAM |
| Memory clock speeds supported by processor | 800,1066 MHz |
| Memory channels | Dual-channel |
| ECC | No |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card model | Intel® HD Graphics |
| On-board graphics card base frequency | 500 MHz |
| On-board graphics card dynamic frequency (max) | 766 MHz |
| Number of displays supported (on-board graphics) | 2 |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Maximum number of PCI Express lanes | 16 |
| PCI Express slots version | 2.0 |
| PCI Express configurations | 1x16 |
| Number of Processing Die Transistors | 382 M |
| Processing Die size | 81 mm² |
| Number of Graphics & IMC Die Transistors | 177 M |
| Graphics & IMC Die Size | 114 mm² |
| Supported instruction sets | SSE4.1, SSE4.2 |
| Embedded options available | No |
| Graphics & IMC lithography | 45 nm |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel FDI Technology | Yes |
| Intel Fast Memory Access | Yes |
| Intel Flex Memory Access | Yes |
| Intel Trusted Execution Technology | No |
| Intel® AES New Instructions (Intel® AES-NI) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Smart Cache | Yes |
| Intel® Turbo Boost Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel® vPro™ Platform Eligibility | No |
Operational conditions
| Specification | Value |
|---|---|
| Tjunction | 105 °C |
Other features
| Specification | Value |
|---|---|
| Intel® Virtualization Technology (Intel® VT) | VT-x |
