Intel Core i5-10400F
Model Intel Core i5-10400FPart no. 296B5AV
75 specifications Checked today
- ProcessorIntel® Core™ i5
- GraphicsNot available
- TypeProcessor
- Processor manufacturerIntel
- Maximum internal memory supported by processor128 GB
- Discrete graphics cardNo
Overview
- Processor
- Intel® Core™ i5
- Graphics
- Not available
- Type
- Processor
- Processor manufacturer
- Intel
- Maximum internal memory supported by processor
- 128 GB
- Discrete graphics card
- No
- Brand
- HP
- Category
- CPU
- Model
- Intel Core i5-10400F
- Part numbers
- 296B5AV, 1P1G1AV, 1P1F1AV
- Also known as
- HP Intel Core i5-10400F processor 2.9 GHz 12 MB Smart Cache
Specifications
75 specifications in 9 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i5 |
| Processor generation | 10th gen Intel® Core™ i5 |
| Processor model | i5-10400F |
| Processor base frequency | 2.9 GHz |
| Processor cores | 6 |
| Processor socket | LGA 1200 (Socket H5) |
| Processor lithography | 14 nm |
| Component for | PC |
| Processor threads | 12 |
| System bus rate | 8 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 4.3 GHz |
| Processor cache | 12 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 65 W |
| Memory bandwidth supported by processor (max) | 41.6 GB/s |
| Processor codename | Comet Lake |
| Processor ARK ID | 199278 |
| Generation | 10th Generation |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 128 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2666 MHz |
| Memory channels | Dual-channel |
| ECC | No |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | No |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Desktop |
| Maximum number of PCI Express lanes | 16 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x16, 2x8, 1x8+2x4 |
| Supported instruction sets | SSE4.1, SSE4.2, AVX 2.0 |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| PCI Express CEM revision | 3.0 |
| Scalability | 1S |
| Thermal solution specification | PCG 2015C |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Thermal Velocity Boost | No |
| Intel® Turbo Boost Technology 2.0 frequency | 4.3 GHz |
| Intel® Transactional Synchronization Extensions | No |
| Intel 64 | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel Turbo Boost Max Technology 3.0 | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Boot Guard | Yes |
| Intel® OS Guard | Yes |
| Intel® Optane™ Memory Ready | Yes |
| Intel® Secure Key | Yes |
| Intel® vPro™ Platform Eligibility | No |
Operational conditions
| Specification | Value |
|---|---|
| Tjunction | 100 °C |
Technical details
| Specification | Value |
|---|---|
| Product type | Processor |
| Supported memory types | DDR4-SDRAM |
| Target market | Gaming |
| Bus speed | 8 GT/s |
| Launch date | Q2'20 |
| Maximum memory | 128 GB |
| Status | Launched |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 8542310001 |
Other features
| Specification | Value |
|---|---|
| Maximum internal memory | 128 GB |
