HP DL170e G6 Intel Xeon L5630 Processor Kit
Model DL170e G6 Intel Xeon L5630 Processor KitPart no. 612468-B21
22 specifications Checked 5 days ago
- ProcessorIntel® Xeon® 5000 Sequence
- Market segmentDesktop
- Maximum operating temperature63.1 °C
Overview
- Processor
- Intel® Xeon® 5000 Sequence
- Market segment
- Desktop
- Maximum operating temperature
- 63.1 °C
- Brand
- HP
- Category
- CPU
- Model
- DL170e G6 Intel Xeon L5630 Processor Kit
- Part number
- 612468-B21
- Also known as
- HP DL170e G6 Intel Xeon L5630 Kit processor 2.13 GHz 12 MB L3 Tray
Specifications
22 specifications in 4 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Xeon® 5000 Sequence |
| Processor model | L5630 |
| Processor base frequency | 2.13 GHz |
| Processor cores | 4 |
| Processor socket | Socket B (LGA 1366) |
| Processor lithography | 32 nm |
| Package type | Tray |
| Component for | PC |
| Processor threads | 8 |
| System bus rate | 5.86 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 2.4 GHz |
| Processor cache | 12 MB |
| Processor cache type | L3 |
| Thermal Design Power (TDP) | 40 W |
| Processor core voltage (AC) | 1.4 V |
| VID Voltage Range | 0.750 - 1.350 V |
| CPU multiplier (bus/core ratio) | 16 |
Features
| Specification | Value |
|---|---|
| Market segment | Desktop |
| Bandwidth | 25600 MB/s |
Operational conditions
| Specification | Value |
|---|---|
| Maximum operating temperature | 63.1 °C |
Other features
| Specification | Value |
|---|---|
| L1 cache | 0.256 MB |
