Fujitsu Xeon E5-2420 6C/12T 1.90 GHz 15 MB

Fujitsu Xeon E5-2420 6C/12T 1.90 GHz 15 MB

Model Xeon E5-2420 6C/12T 1.90 GHz 15 MBPart no. S26361-F3723-L190EAN 5054484202028

47 specifications Checked 2 days ago
  • ProcessorIntel® Xeon® E5 Family
  • Maximum internal memory supported by processor375 GB
  • On-board graphics cardNo
  • Execute Disable BitYes
See all specifications

Overview

Processor
Intel® Xeon® E5 Family
Maximum internal memory supported by processor
375 GB
On-board graphics card
No
Execute Disable Bit
Yes
Brand
Fujitsu
Category
CPU
Model
Xeon E5-2420 6C/12T 1.90 GHz 15 MB
Part number
S26361-F3723-L190
EAN / UPC
5054484202028, 4051554449063, 4053162300309, 5054533202023 +1 more
Also known as
Fujitsu Xeon E5-2420 6C/12T 1.90 GHz 15 MB processor 1.9 GHz L3

Specifications

47 specifications in 6 groups

Processor

Processor familyIntel® Xeon® E5 Family
Processor modelE5-2420
Processor base frequency1.9 GHz
Processor cores6
Processor socketLGA 1356 (Socket B2)
Processor lithography32 nm
Component forServer/workstation
Processor threads12
System bus rate7.2 GT/s
Processor operating modes64-bit
Processor boost frequency2.4 GHz
Processor cache15 MB
Processor cache typeL3
Processor front side bus1333 MHz
Thermal Design Power (TDP)95 W
VID Voltage Range0.6 - 1.35 V
Bus typeQPI
Number of QPI links1
Memory bandwidth supported by processor (max)32 GB/s

Memory

Maximum internal memory supported by processor375 GB
Memory types supported by processorDDR3-SDRAM
Memory clock speeds supported by processor800,1066,1333 MHz
Memory channelsTriple-channel
ECCYes

Graphics

On-board graphics cardNo

Features

Execute Disable BitYes
Idle StatesYes
Thermal Monitoring TechnologiesYes
Market segmentServer
Maximum number of PCI Express lanes24
PCI Express slots version3.0
CPU configuration (max)2
Embedded options availableNo
ScalabilityS2S

Processor special features

Enhanced Intel SpeedStep TechnologyYes
Intel Flex Memory AccessYes
Intel Trusted Execution TechnologyYes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Turbo Boost TechnologyYes
Intel Demand Based SwitchingYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel Virtualization Technology (VT-x)Yes
Intel Virtualization Technology for Directed I/O (VT-d)Yes
Intel® vPro™ Platform EligibilityYes

Other features

Intel® Virtualization Technology (Intel® VT)VT-d, VT-x
CompatibilityPRIMERGY TX200 S7
