Fujitsu Xeon Bronze 3104
Model Xeon Bronze 3104Part no. S26361-F4051-L104EAN 4059595365618
46 specifications Checked 3 days ago
- ProcessorIntel® Xeon®
- Maximum internal memory supported by processor768 GB
- On-board graphics cardNo
- Execute Disable BitYes
- Tcase78 °C
- Processor package size76.0 x 56.5 mm
Overview
- Processor
- Intel® Xeon®
- Maximum internal memory supported by processor
- 768 GB
- On-board graphics card
- No
- Execute Disable Bit
- Yes
- Tcase
- 78 °C
- Processor package size
- 76.0 x 56.5 mm
- Brand
- Fujitsu
- Category
- CPU
- Model
- Xeon Bronze 3104
- Part number
- S26361-F4051-L104
- EAN / UPC
- 4059595365618
- Also known as
- Fujitsu Xeon Bronze 3104 processor 1.7 GHz 8.25 MB L3 Box
Specifications
46 specifications in 7 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Xeon® |
| Processor generation | 1st Generation Intel® Xeon® Scalable |
| Processor model | 3104 |
| Processor base frequency | 1.7 GHz |
| Processor cores | 6 |
| Processor socket | LGA 3647 (Socket P) |
| Processor lithography | 14 nm |
| Package type | Box |
| Component for | Server/workstation |
| Processor threads | 6 |
| Processor operating modes | 64-bit |
| Processor cache | 8.25 MB |
| Processor cache type | L3 |
| Thermal Design Power (TDP) | 85 W |
| Stepping | U0 |
| Processor codename | Skylake |
| Processor code | SR3GM |
| Processor ARK ID | 123546 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 768 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2133 MHz |
| Memory channels | Hexa-channel |
| ECC | Yes |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Market segment | Server |
| Maximum number of PCI Express lanes | 48 |
| PCI Express slots version | 3.0 |
| Supported instruction sets | AVX, AVX 2.0, AVX-512, SSE4.2 |
| Embedded options available | No |
| Scalability | 2S |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Speed Shift Technology | Yes |
| Intel® Turbo Boost Technology | No |
| Conflict-Free processor | Yes |
| Intel 64 | Yes |
| Intel TSX-NI | Yes |
| Intel Turbo Boost Max Technology 3.0 | No |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel® Optane™ Memory Ready | No |
| Intel® vPro™ Platform Eligibility | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tcase | 78 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Processor package size | 76.0 x 56.5 mm |
