Fujitsu Intel Xeon Processor E3-1265L v3
Model Intel Xeon Processor E3-1265L v3Part no. V26808-B9026-V10
104 specifications Checked 2 days ago
- ProcessorIntel® Xeon® E3 V3 Family
- TypeProcessor
- Processor manufacturerIntel
- Maximum internal memory supported by processor32 GB
- On-board graphics cardYes
- Processor cache8192 KB
Overview
- Processor
- Intel® Xeon® E3 V3 Family
- Type
- Processor
- Processor manufacturer
- Intel
- Maximum internal memory supported by processor
- 32 GB
- On-board graphics card
- Yes
- Processor cache
- 8192 KB
- Brand
- Fujitsu
- Category
- CPU
- Model
- Intel Xeon Processor E3-1265L v3
- Part number
- V26808-B9026-V10
- Also known as
- Fujitsu Intel Xeon E3-1265L v3 processor 2.5 GHz 8 MB Smart Cache
Specifications
104 specifications in 9 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® E3 V3 Family |
| Processor model | E3-1265LV3 |
| Processor base frequency | 2.5 GHz |
| Processor cores | 4 |
| Processor socket | LGA 1150 (Socket H3) |
| Processor lithography | 22 nm |
| Component for | Server/workstation |
| Processor series | Intel Xeon E3-1200 v3 |
| Processor threads | 8 |
| System bus rate | 5 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.7 GHz |
| Processor cache | 8 MB |
| Processor cache type | Smart Cache |
| L3 cache speed | 2.5 GHz |
| Thermal Design Power (TDP) | 45 W |
| Stepping | C0 |
| Bus type | DMI |
| Number of QPI links | 0 |
| Memory bandwidth supported by processor (max) | 25.6 GB/s |
| Processor codename | Haswell |
| Processor code | SR15A |
| Processor ARK ID | 75463 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 32 GB |
| Memory types supported by processor | DDR3-SDRAM, DDR3L-SDRAM |
| Memory clock speeds supported by processor | 1333,1600 MHz |
| Memory channels | Dual-channel |
| ECC | Yes |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card model | Intel® HD Graphics |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card dynamic frequency (max) | 1200 MHz |
| Number of displays supported (on-board graphics) | 3 |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Server |
| Maximum number of PCI Express lanes | 16 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x16, 2x8, 1x8+2x4 |
| Supported instruction sets | SSE4.1, SSE4.2, AVX 2.0 |
| Bandwidth | 5 MB/s |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Graphics & IMC lithography | 22 nm |
| PCI Express CEM revision | 3.0 |
| Scalability | 1S |
| Thermal solution specification | PCG 2013B |
| Export Control Classification Number (ECCN) | 5A992C |
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Dual Display Capable Technology | Yes |
| Intel FDI Technology | Yes |
| Intel Fast Memory Access | Yes |
| Intel Flex Memory Access | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Anti-Theft Technology (Intel® AT) | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Smart Cache | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Turbo Boost Technology 2.0 frequency | 3.7 GHz |
| Intel® Transactional Synchronization Extensions | Yes |
| Conflict-Free processor | No |
| Intel 64 | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel TSX-NI | Yes |
| Intel TSX-NI version | 1.00 |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® OS Guard | Yes |
| Intel® Secure Key | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
Technical details
| Specification | Value |
|---|---|
| Processor cache | 8192 KB |
| Product type | Processor |
| Supported memory types | DDR3-SDRAM, DDR3L-SDRAM |
| Born on date | Q2'13 |
| Bus bandwidth | 5 |
| Bus speed | 5 GT/s |
| Bus type units | GT/s |
| Graphics max dynamic frequency | 1.20 GHz |
| Last change | 63903513 |
| Launch date | Q2'13 |
| Maximum memory | 32 GB |
| Number of graphics cores | 10 |
| Processor brand name | Intel Xeon v2 |
| Product family | Intel Xeon Processor E3 v3 Family |
| Product name | Intel Xeon E3-1265L v3 (8M Cache, 2.50 GHz) |
| Status | Discontinued |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 8542310001 |
Weight & dimensions
| Specification | Value |
|---|---|
| Processor package size | 37.5 x 37.5 mm |
Other features
| Specification | Value |
|---|---|
| Intel® Virtualization Technology (Intel® VT) | VT-d, VT-x |
| Cache memory | 8 MB |
| Maximum internal memory | 32 GB |
| Maximum internal memory | 32768 MB |
