Intel Xeon Phi 7290F
Model Intel Xeon Phi 7290FPart no. S26361-F4022-E290
48 specifications Checked today
- ProcessorIntel® Xeon Phi™
- GraphicsNot available
- Maximum internal memory supported by processor384 GB
- Discrete graphics cardNo
- Execute Disable BitYes
Overview
- Processor
- Intel® Xeon Phi™
- Graphics
- Not available
- Maximum internal memory supported by processor
- 384 GB
- Discrete graphics card
- No
- Execute Disable Bit
- Yes
- Brand
- Fujitsu
- Category
- CPU
- Model
- Intel Xeon Phi 7290F
- Part number
- S26361-F4022-E290
- Also known as
- Fujitsu Xeon Intel Phi 7290F processor 1.50 GHz 36 MB L2
Specifications
48 specifications in 6 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Xeon Phi™ |
| Processor model | 7290F |
| Processor base frequency | 1.50 GHz |
| Processor cores | 72 |
| Processor socket | LGA 3647 (Socket P) |
| Processor lithography | 14 nm |
| Component for | Server/workstation |
| Processor series | Intel Xeon Phi Processor 7200 Series |
| Processor operating modes | 64-bit |
| Processor boost frequency | 1.70 GHz |
| Processor cache | 36 MB |
| Processor cache type | L2 |
| Thermal Design Power (TDP) | 260 W |
| VID Voltage Range | 0.55 - 1.125 V |
| Stepping | B0 |
| Memory bandwidth supported by processor (max) | 115.2 GB/s |
| Processor codename | Knights landing |
| Processor code | SR2WZ |
| Processor ARK ID | 95831 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 384 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2400 MHz |
| Memory channels | Hexa-channel |
| ECC | Yes |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| Discrete graphics card model | Not available |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Server |
| Maximum number of PCI Express lanes | 4 |
| PCI Express slots version | 3.0 |
| Supported instruction sets | AVX-512 |
| Embedded options available | No |
| PCI Express CEM revision | 3.0 |
Processor special features
| Specification | Value |
|---|---|
| Intel Trusted Execution Technology | No |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Memory Protection Extensions (Intel® MPX) | No |
| Intel® Turbo Boost Technology | 2.0 |
| Conflict-Free processor | Yes |
| Intel 64 | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Software Guard Extensions (Intel SGX) | No |
| Intel VT-x with Extended Page Tables (EPT) | No |
| Intel Virtualization Technology (VT-x) | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel® Boot Guard | No |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 8542310001 |
