Intel Xeon E7-8894V4
Model Intel Xeon E7-8894V4Part no. S26361-F3896-E494
69 specifications Checked today
- ProcessorIntel Xeon E7 v4
- GraphicsNot available
- Maximum internal memory supported by processor3 TB
- Discrete graphics cardNo
- Execute Disable BitYes
- Tcase79 °C
Overview
- Processor
- Intel Xeon E7 v4
- Graphics
- Not available
- Maximum internal memory supported by processor
- 3 TB
- Discrete graphics card
- No
- Execute Disable Bit
- Yes
- Tcase
- 79 °C
- Brand
- Fujitsu
- Category
- CPU
- Model
- Intel Xeon E7-8894V4
- Part numbers
- S26361-F3896-E494, S26361-F3896-L494
- Also known as
- Fujitsu Xeon Intel E7-8894V4 processor 2.40 GHz 60 MB Smart Cache
Specifications
69 specifications in 8 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel Xeon E7 v4 |
| Processor model | E7-8894V4 |
| Processor base frequency | 2.40 GHz |
| Processor cores | 24 |
| Processor socket | LGA 2011 (Socket R) |
| Processor lithography | 14 nm |
| Component for | Server/workstation |
| Processor series | Intel Xeon E7-8800 v4 |
| Processor threads | 48 |
| System bus rate | 9.6 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.40 GHz |
| Processor cache | 60 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 165 W |
| Stepping | B0 |
| Bus type | QPI |
| Number of QPI links | 3 |
| Memory bandwidth supported by processor (max) | 85 GB/s |
| Processor codename | Broadwell |
| Processor code | SR32U |
| Processor ARK ID | 96900 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 3 TB |
| Memory types supported by processor | DDR3-SDRAM, DDR4-SDRAM |
| Memory clock speeds supported by processor | 1066,1333,1600,1866 MHz |
| Memory channels | Quad-channel |
| ECC | Yes |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | No |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Server |
| Maximum number of PCI Express lanes | 32 |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x16, 1x4, 1x8 |
| Supported instruction sets | AVX 2.0 |
| CPU configuration (max) | 8 |
| Embedded options available | No |
| PCI Express CEM revision | 3.0 |
| Physical Address Extension (PAE) | 46 bit |
| Physical Address Extension (PAE) | Yes |
| Scalability | S8S |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Flex Memory Access | No |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Conflict-Free processor | Yes |
| Intel 64 | Yes |
| Intel Demand Based Switching | No |
| Intel Enhanced Halt State | Yes |
| Intel Instruction Replay Technology | No |
| Intel Instruction Replay Technology version | 0.00 |
| Intel Secure Key Technology version | 1.00 |
| Intel TSX-NI | Yes |
| Intel TSX-NI version | 1.00 |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® OS Guard | Yes |
| Intel® Secure Key | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tcase | 79 °C |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 8542310001 |
Weight & dimensions
| Specification | Value |
|---|---|
| Processor package size | 45 x 52.5 mm |
