Fujitsu Intel Xeon E5-2660 v4

Fujitsu Intel Xeon E5-2660 v4

Model Intel Xeon E5-2660 v4Part no. S26361-F5002-L266EAN 4057185690706

50 specifications Checked 2 days ago
  • ProcessorIntel® Xeon® E5 v4
  • GraphicsNot available
  • Memory types supported by processorDDR4-SDRAM
  • Discrete graphics cardNo
  • Execute Disable BitYes
See all specifications

Overview

Processor
Intel® Xeon® E5 v4
Graphics
Not available
Memory types supported by processor
DDR4-SDRAM
Discrete graphics card
No
Execute Disable Bit
Yes
Brand
Fujitsu
Category
CPU
Model
Intel Xeon E5-2660 v4
Part numbers
S26361-F5002-L266, S26361-F3933-L560, S26361-F3933-E160, S26361-F3933-L360, S26361-F3933-L460
EAN / UPC
4057185690706, 4057185706452
Also known as
Fujitsu Intel Xeon E5-2660 v4 processor 2 GHz 35 MB Smart Cache

Specifications

50 specifications in 5 groups

Processor

Processor familyIntel® Xeon® E5 v4
Processor modelE5-2660V4
Processor base frequency2 GHz
Processor cores14
Processor socketLGA 2011-v3
Processor lithography14 nm
Component forServer/workstation
Processor seriesIntel Xeon E5-2600 v4
Processor threads28
System bus rate9.6 GT/s
Processor operating modes64-bit
Processor boost frequency3.2 GHz
Processor cache35 MB
Processor cache typeSmart Cache
Thermal Design Power (TDP)105 W
SteppingM0
Bus typeQPI
Number of QPI links2
Memory bandwidth supported by processor (max)76.8 GB/s
Processor codenameBroadwell

Memory

Memory types supported by processorDDR4-SDRAM
Memory clock speeds supported by processor1600,1866,2133,2400 MHz
Memory channelsQuad-channel
ECCYes

Graphics

Discrete graphics cardNo
On-board graphics cardNo
On-board graphics card modelNot available
Discrete graphics card modelNot available

Features

Execute Disable BitYes
Idle StatesYes
Thermal Monitoring TechnologiesYes
Market segmentServer
Maximum number of PCI Express lanes40
PCI Express slots version3.0
Supported instruction setsAVX 2.0
CPU configuration (max)2
Physical Address Extension (PAE)46 bit
Physical Address Extension (PAE)Yes
Scalability2S

Processor special features

Enhanced Intel SpeedStep TechnologyYes
Intel Trusted Execution TechnologyYes
Intel® AES New Instructions (Intel® AES-NI)Yes
Intel® Hyper Threading Technology (Intel® HT Technology)Yes
Intel® Turbo Boost Technology2.0
Intel Demand Based SwitchingYes
Intel Enhanced Halt StateYes
Intel TSX-NIYes
Intel VT-x with Extended Page Tables (EPT)Yes
Intel® Secure KeyYes
Intel® vPro™ Platform EligibilityYes
