Fujitsu Intel Xeon E3-1220 V2
Model Intel Xeon E3-1220 V2Part no. V26808-B8662-V10
56 specifications Checked 2 days ago
- ProcessorIntel® Xeon® E3 V2 Family
- GraphicsNot available
- Processor manufacturerIntel
- Maximum internal memory supported by processor32.23 GB
- Discrete graphics cardNo
- Execute Disable BitYes
Overview
- Processor
- Intel® Xeon® E3 V2 Family
- Graphics
- Not available
- Processor manufacturer
- Intel
- Maximum internal memory supported by processor
- 32.23 GB
- Discrete graphics card
- No
- Execute Disable Bit
- Yes
- Brand
- Fujitsu
- Category
- CPU
- Model
- Intel Xeon E3-1220 V2
- Part number
- V26808-B8662-V10
- Also known as
- Fujitsu Intel Xeon E3-1220 V2 processor 2.3 GHz 3 MB Smart Cache
Specifications
56 specifications in 6 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® E3 V2 Family |
| Processor model | E3-1220LV2 |
| Processor base frequency | 2.3 GHz |
| Processor cores | 2 |
| Processor socket | LGA 1155 (Socket H2) |
| Processor lithography | 22 nm |
| Cooler included | No |
| Component for | Server/workstation |
| Processor series | Intel Xeon E3-1200 v2 |
| Processor threads | 4 |
| System bus rate | 5 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.5 GHz |
| Processor cache | 3 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 17 W |
| Stepping | L1 |
| Bus type | DMI |
| Memory bandwidth supported by processor (max) | 25.6 GB/s |
| Processor codename | Ivy Bridge |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 32.23 GB |
| Memory types supported by processor | DDR3-SDRAM |
| Memory clock speeds supported by processor | 1333,1600 MHz |
| Memory channels | Dual-channel |
| ECC | Yes |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | No |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Server |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x4, 1x16+1x4, 1x8, 2x8 |
| Supported instruction sets | AVX, SSE4.1, SSE4.2 |
| CPU configuration (max) | 1 |
| Embedded options available | No |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Fast Memory Access | Yes |
| Intel Flex Memory Access | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Conflict-Free processor | Yes |
| Intel 64 | Yes |
| Intel Demand Based Switching | Yes |
| Intel TSX-NI | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
Other features
| Specification | Value |
|---|---|
| Compatibility | Primergy BX620 S4 |
