Fujitsu Intel Pentium G3450

Model Intel Pentium G3450Part no. 38041708

113 specifications Checked 2 days ago

Overview

Brand: Fujitsu
Category: CPU
Model: Intel Pentium G3450
Part number: 38041708
Also known as: Fujitsu Intel Pentium G3450 processor 3.4 GHz 3 MB Smart Cache

113 specifications in 10 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Pentium G
Processor model	G3450
Processor base frequency	3.4 GHz
Processor cores	2
Processor socket	LGA 1150 (Socket H3)
Processor lithography	22 nm
Component for	PC
Processor threads	2
System bus rate	5 GT/s
Processor operating modes	64-bit
Processor cache	3 MB
Processor cache type	Smart Cache
Thermal Design Power (TDP)	53 W
Stepping	C0
Bus type	DMI
Number of QPI links	0
Memory bandwidth supported by processor (max)	25.6 GB/s
Processor codename	Haswell
Processor code	SR1K2
Processor ARK ID	80792

Specification	Value
Maximum internal memory supported by processor	32 GB
Memory types supported by processor	DDR3-SDRAM, DDR3L-SDRAM
Memory clock speeds supported by processor	1333,1600 MHz
Memory channels	Dual-channel
ECC	Yes

Specification	Value
Discrete graphics card	No
On-board graphics card	Yes
On-board graphics card model	Intel® HD Graphics
Maximum on-board graphics card memory	1.7 GB
On-board graphics card outputs supported	Embedded DisplayPort (eDP), DisplayPort, HDMI, DVI, VGA (D-Sub)
On-board graphics card base frequency	350 MHz
On-board graphics card dynamic frequency (max)	1100 MHz
Number of displays supported (on-board graphics)	3
On-board graphics card DirectX version	11.1
On-board graphics card OpenGL version	4.3
On-board graphics card maximum resolution (DisplayPort)	2560 x 1600 pixels
On-board graphics card maximum resolution (HDMI)	1920 x 1080 pixels
On-board graphics card maximum resolution (VGA)	1920 x 1200 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)	2560 x 1600 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)	60 Hz
On-board graphics card refresh rate at maximum resolution (VGA)	60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)	60 Hz

Specification	Value
Execute Disable Bit	Yes
Idle States	Yes
Thermal Monitoring Technologies	Yes
Market segment	Desktop
Maximum number of PCI Express lanes	16
PCI Express slots version	3.0
PCI Express configurations	1x16, 2x8, 1x8+2x4
Supported instruction sets	SSE4.1, SSE4.2
Bandwidth	5 MB/s
CPU configuration (max)	1
Embedded options available	No
Graphics & IMC lithography	22 nm
Scalability	1S
Thermal solution specification	PCG 2013C
Export Control Classification Number (ECCN)	3A991
Commodity Classification Automated Tracking System (CCATS)	NA

Specification	Value
Enhanced Intel SpeedStep Technology	Yes
Intel Trusted Execution Technology	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Quick Sync Video Technology	Yes
Intel® Smart Cache	Yes
Intel® Turbo Boost Technology	No
Intel® Wireless Display (Intel® WiDi)	Yes
Intel® Transactional Synchronization Extensions	No
Conflict-Free processor	Yes
Intel 64	Yes
Intel Enhanced Halt State	Yes
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP)	No
Intel TSX-NI	No
Intel TSX-NI version	0.00
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® Optane™ Memory Ready	No
Intel® Secure Key	Yes
Intel® vPro™ Platform Eligibility	No

Specification	Value
Tcase	72 °C

Specification	Value
Maximum graphics card memory	1.7 GB
Maximum graphics card memory	1740 MB
Processor cache	3072 KB
Product type	Processor
Supported memory types	DDR3-SDRAM, DDR3L-SDRAM
Born on date	Q2'14
Bus bandwidth	5
Bus speed	5 GT/s
Bus type units	GT/s
Graphics max dynamic frequency	1.10 GHz
Last change	63903513
Launch date	Q2'14
Maximum memory	32 GB
Maximum resolution & refresh rate (DisplayPort)	2560x1600@60Hz
Maximum resolution & refresh rate (HDMI)	1920x1080@60Hz
Maximum resolution & refresh rate (Integrated Flat Panel)	2560x1600@60Hz
Maximum resolution & refresh rate (VGA)	1920x1200@60Hz
Number of graphics cores	10
OpenGL support	Yes
Processor brand name	Intel Pentium
Product family	Intel Pentium Processor
Product name	Intel Pentium G3450 (3M Cache, 3.40 GHz)
Status	Discontinued

Specification	Value
Harmonized System (HS) code	8542310001

Specification	Value
Processor package size	37.5 x 37.5 mm
