Intel Core i7-1185G7
Model Intel Core i7-1185G7Part no. FPCCPV81BK
87 specifications Checked today
- ProcessorIntel® Core™ i7
- GraphicsNot available
- Processor manufacturerIntel
- Maximum internal memory supported by processor64 GB
- Discrete graphics cardNo
- Idle StatesYes
Overview
- Processor
- Intel® Core™ i7
- Graphics
- Not available
- Processor manufacturer
- Intel
- Maximum internal memory supported by processor
- 64 GB
- Discrete graphics card
- No
- Idle States
- Yes
- Brand
- Fujitsu
- Category
- CPU
- Model
- Intel Core i7-1185G7
- Part number
- FPCCPV81BK
- Also known as
- Fujitsu Core Intel i7-1185G7 processor 12 MB Smart Cache Tray
Specifications
87 specifications in 10 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i7 |
| Processor generation | 11th gen Intel® Core™ i7 |
| Processor model | i7-1185G7 |
| Processor cores | 4 |
| Processor socket | BGA 1449 |
| Processor lithography | 10 nm |
| Package type | Tray |
| Cooler included | No |
| Component for | Laptop |
| Processor threads | 8 |
| System bus rate | 4 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 4.8 GHz |
| Processor cache | 12 MB |
| Processor cache type | Smart Cache |
| Configurable TDP-up frequency | 3 GHz |
| Configurable TDP-up | 28 W |
| Configurable TDP-down frequency | 1.2 GHz |
| Configurable TDP-down | 12 W |
| Processor codename | Tiger Lake |
| Processor ARK ID | 208664 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 64 GB |
| Memory types supported by processor | DDR4-SDRAM, LPDDR4x-SDRAM |
| Memory clock speeds supported by processor | 4267,3200 MHz |
| Memory channels | Dual-channel |
| ECC | No |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | Yes |
| On-board graphics card model | Intel Iris Xe Graphics |
| On-board graphics card outputs supported | DisplayPort 1.4, MIPI-DSI 2.0, Embedded DisplayPort (eDP) 1.4b, HDMI 2.0b |
| On-board graphics card dynamic frequency (max) | 1350 MHz |
| Number of displays supported (on-board graphics) | 4 |
| On-board graphics card OpenGL version | 4.6 |
| On-board graphics card maximum resolution (DisplayPort) | 7680 x 4320 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (eDP - Integrated Flat Panel) | 4096 x 2304 pixels |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel) | 60 Hz |
| On-board graphics card ID | 0x9A49 |
| Discrete graphics card model | Not available |
| Number of execution units | 96 |
Features
| Specification | Value |
|---|---|
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Mobile |
| PCI Express slots version | 3.0, 4.0 |
| Supported instruction sets | SSE4.1, SSE4.2, AVX 2.0, AVX-512 |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Export Control Classification Number (ECCN) | 5A992CN3 |
| Commodity Classification Automated Tracking System (CCATS) | G167599 |
Processor special features
| Specification | Value |
|---|---|
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 2.0 | Yes |
| Intel® Thunderbolt 4 | Yes |
| Intel® Adaptix Technology | Yes |
| Intel® Image Processing Unit | 6.0 |
| Intel® Wake on Voice | Yes |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Intel Software Guard Extensions (Intel SGX) | No |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Boot Guard | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
| Intel® OS Guard | Yes |
| Intel® Optane™ Memory Ready | Yes |
| Intel® Smart Sound Technology | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
| Mode-based Execute Control (MBE) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tjunction | 100 °C |
Technical details
| Specification | Value |
|---|---|
| OpenCL version | 2.0 |
| Supported memory types | DDR4-SDRAM, LPDDR4x-SDRAM |
| Launch date | Q3'20 |
| Status | Launched |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 8542310001 |
Weight & dimensions
| Specification | Value |
|---|---|
| Processor package size | 46.5mm x 25mm |
Other features
| Specification | Value |
|---|---|
| Maximum internal memory | 64 GB |
