Fujitsu Intel Core i5-660
Model Intel Core i5-660Part no. 34027204EAN 4054318647309
57 specifications Checked 3 days ago
- ProcessorIntel® Core™ i5
- GraphicsNot available
- Maximum internal memory supported by processor16.38 GB
- Discrete graphics cardNo
- Execute Disable BitYes
- Tcase72.6 °C
Overview
- Processor
- Intel® Core™ i5
- Graphics
- Not available
- Maximum internal memory supported by processor
- 16.38 GB
- Discrete graphics card
- No
- Execute Disable Bit
- Yes
- Tcase
- 72.6 °C
- Brand
- Fujitsu
- Category
- CPU
- Model
- Intel Core i5-660
- Part number
- 34027204
- EAN / UPC
- 4054318647309
- Also known as
- Fujitsu Intel Core i5-660 processor 3.33 GHz 4 MB Smart Cache
Specifications
57 specifications in 6 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Core™ i5 |
| Processor generation | Intel® Core™ i5 |
| Processor model | i5-660 |
| Processor base frequency | 3.33 GHz |
| Processor cores | 2 |
| Processor socket | LGA 1156 (Socket H) |
| Processor lithography | 32 nm |
| Component for | PC |
| Processor threads | 4 |
| System bus rate | 2.5 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.6 GHz |
| Processor cache | 4 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 73 W |
| VID Voltage Range | 0.65 - 1.4 V |
| Bus type | DMI |
| Memory bandwidth supported by processor (max) | 21 GB/s |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 16.38 GB |
| Memory types supported by processor | DDR3-SDRAM |
| Memory clock speeds supported by processor | 1066,1333 MHz |
| Memory channels | Dual-channel |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | Yes |
| On-board graphics card model | Intel® HD Graphics |
| On-board graphics card base frequency | 733 MHz |
| Number of displays supported (on-board graphics) | 2 |
| Discrete graphics card model | Not available |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | No |
| Market segment | Desktop |
| Maximum number of PCI Express lanes | 16 |
| PCI Express slots version | 2.0 |
| PCI Express configurations | 1x16, 2x8 |
| Number of Processing Die Transistors | 382 M |
| Processing Die size | 81 mm² |
| Supported instruction sets | SSE4.2 |
| CPU configuration (max) | 1 |
| Embedded options available | Yes |
| Physical Address Extension (PAE) | 36 bit |
| Physical Address Extension (PAE) | Yes |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel FDI Technology | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Smart Cache | Yes |
| Intel® Turbo Boost Technology | 1.0 |
| Intel 64 | Yes |
| Intel Demand Based Switching | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tcase | 72.6 °C |
