Fujitsu Intel Core i5-4300U
Model Intel Core i5-4300UPart no. S26391-F1341-E430
87 specifications Checked 4 days ago
- ProcessorIntel® Core™ i5
- Type5
- Maximum internal memory supported by processor16 GB
- On-board graphics cardYes
- USB version3.2 Gen 1 (3.1 Gen 1)
- Maximum graphics card memory1740 MB
Overview
- Processor
- Intel® Core™ i5
- Type
- 5
- Maximum internal memory supported by processor
- 16 GB
- On-board graphics card
- Yes
- USB version
- 3.2 Gen 1 (3.1 Gen 1)
- Maximum graphics card memory
- 1740 MB
- Brand
- Fujitsu
- Category
- CPU
- Model
- Intel Core i5-4300U
- Part number
- S26391-F1341-E430
- Also known as
- Fujitsu Intel Core i5-4300U processor 1.9 GHz 3 MB Smart Cache
Specifications
87 specifications in 8 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Core™ i5 |
| Processor generation | 4th gen Intel® Core™ i5 |
| Processor model | i5-4300U |
| Processor base frequency | 1.9 GHz |
| Processor cores | 2 |
| Processor socket | BGA 1168 |
| Processor lithography | 22 nm |
| Component for | Laptop |
| Processor series | Intel Core i5-4300 Mobile series |
| Processor threads | 4 |
| System bus rate | 5 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 2.9 GHz |
| Processor cache | 3 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 15 W |
| Bus type | DMI2 |
| Memory bandwidth supported by processor (max) | 25.6 GB/s |
| Processor codename | Haswell |
| Processor ARK ID | 76308 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 16 GB |
| Memory types supported by processor | DDR3L |
| Memory clock speeds supported by processor | 1333,1600 MHz |
| Memory channels | Dual-channel |
| ECC | No |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | Yes |
| On-board graphics card model | Intel® HD Graphics 4400 |
| Maximum on-board graphics card memory | 1.74 GB |
| On-board graphics card outputs supported | DisplayPort, Embedded DisplayPort (eDP), HDMI |
| On-board graphics card base frequency | 200 MHz |
| On-board graphics card dynamic frequency (max) | 1100 MHz |
| Number of displays supported (on-board graphics) | 3 |
| On-board graphics card DirectX version | 11.2/12 |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Mobile |
| Maximum number of PCI Express lanes | 12 |
| PCI Express slots version | 2.0 |
| PCI Express configurations | 2x4, 4x1 |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| CPU configuration (max) | 1 |
| Embedded options available | Yes |
I/O configuration
| Specification | Value |
|---|---|
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| USB ports quantity | 4 |
| Total number of SATA connectors | 4 |
| Number of SATA III connectors | 4 |
| Integrated LAN | No |
| General Purpose IO | Yes |
| UART | Yes |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel FDI Technology | Yes |
| Intel Smart Connect Technology | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Anti-Theft Technology (Intel® AT) | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
| Intel® InTru™ 3D Technology | Yes |
| Intel® Insider™ | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Smart Cache | Yes |
| Intel® Smart Response Technology | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Wireless Display (Intel® WiDi) | Yes |
| Conflict-Free processor | Yes |
| Intel 64 | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Identity Protection Technology version | 1.00 |
| Intel ME Firmware Version | 9.5 |
| Intel Rapid Storage Technology | Yes |
| Intel Stable Image Platform Program (SIPP) | Yes |
| Intel TSX-NI | No |
| Intel TSX-NI version | 0.00 |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
| Intel® Matrix Storage Technology (Intel® MST) | No |
| Intel® Secure Key | Yes |
| Intel® Small Business Advantage (Intel® SBA) | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
Technical details
| Specification | Value |
|---|---|
| Maximum graphics card memory | 1740 MB |
| Processor cache | 3072 KB |
| Product type | 5 |
Weight & dimensions
| Specification | Value |
|---|---|
| Processor package size | 40 mm |
