Xeon Platinum 8168 (33M Cache, 2.70 GHz)
Model Xeon Platinum 8168 (33M Cache, 2.70 GHz)Part no. PROPT81681SF
56 specifications Checked today
- ProcessorIntel® Xeon® Platinum
- GraphicsNot available
- Type4
- Processor manufacturerIntel
- Maximum internal memory supported by processor768 GB
- Discrete graphics cardNo
Overview
- Processor
- Intel® Xeon® Platinum
- Graphics
- Not available
- Type
- 4
- Processor manufacturer
- Intel
- Maximum internal memory supported by processor
- 768 GB
- Discrete graphics card
- No
- Brand
- EMC
- Category
- CPU
- Model
- Xeon Platinum 8168 (33M Cache, 2.70 GHz)
- Part numbers
- PROPT81681SF, PROPT81682SF
- Also known as
- EMC Xeon Platinum 8168 (33M Cache, 2.70 GHz) processor 33 MB L3
Specifications
56 specifications in 9 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® Platinum |
| Processor generation | 1st Generation Intel® Xeon® Scalable |
| Processor model | 8168 |
| Processor base frequency | 2.70 GHz |
| Processor cores | 24 |
| Processor socket | LGA 3647 (Socket P) |
| Processor lithography | 14 nm |
| Processor threads | 48 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.70 GHz |
| Processor cache | 33 MB |
| Processor cache type | L3 |
| Thermal Design Power (TDP) | 205 W |
| Stepping | H0 |
| Bus type | UPI |
| Processor codename | Skylake |
| Processor code | SR37J |
| Processor ARK ID | 120504 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 768 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2666 MHz |
| Memory channels | Hexa-channel |
| ECC | Yes |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | No |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Maximum number of PCI Express lanes | 48 |
| PCI Express slots version | 3.0 |
| Supported instruction sets | AVX, AVX 2.0, AVX-512, SSE4.2 |
| Embedded options available | No |
| Scalability | S8S |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Conflict-Free processor | Yes |
| Intel 64 | Yes |
| Intel TSX-NI | Yes |
| Intel Turbo Boost Max Technology 3.0 | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Optane™ Memory Ready | No |
| Intel® vPro™ Platform Eligibility | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tcase | 85 °C |
Technical details
| Specification | Value |
|---|---|
| Processor cache | 33792 KB |
| Product type | 4 |
| Product family | Intel Xeon Processors |
| Status | Launched |
Weight & dimensions
| Specification | Value |
|---|---|
| Processor package size | 76 x 56.5 mm |
Other features
| Specification | Value |
|---|---|
| Maximum internal memory | 786432 MB |
