Dell Xeon E3-1220 V2
Model Xeon E3-1220 V2Part no. 213-16118
47 specifications Checked 3 days ago
- ProcessorIntel® Xeon® E3 V2 Family
- Maximum internal memory supported by processor32 GB
- On-board graphics cardNo
- Execute Disable BitYes
Overview
- Processor
- Intel® Xeon® E3 V2 Family
- Maximum internal memory supported by processor
- 32 GB
- On-board graphics card
- No
- Execute Disable Bit
- Yes
- Brand
- Dell
- Category
- CPU
- Model
- Xeon E3-1220 V2
- Part number
- 213-16118
- Also known as
- DELL Xeon E3-1220 V2 processor 3.1 GHz 8 MB L3 Box
Specifications
47 specifications in 6 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Xeon® E3 V2 Family |
| Processor model | E3-1220V2 |
| Processor base frequency | 3.1 GHz |
| Processor cores | 4 |
| Processor socket | LGA 1155 (Socket H2) |
| Processor lithography | 28 nm |
| Package type | Box |
| Component for | Server/workstation |
| Processor threads | 4 |
| System bus rate | 5 GT/s |
| Processor operating modes | 32-bit, 64-bit |
| Processor boost frequency | 3.5 GHz |
| Processor cache | 8 MB |
| Processor cache type | L3 |
| L3 cache speed | 3.1 GHz |
| Thermal Design Power (TDP) | 69 W |
| Stepping | E1 |
| Bus type | DMI |
| CPU multiplier (bus/core ratio) | 31 |
| Memory bandwidth supported by processor (max) | 25.6 GB/s |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 32 GB |
| Memory types supported by processor | DDR3-SDRAM |
| Memory clock speeds supported by processor | 1333,1600 MHz |
| Memory channels | Dual-channel |
| ECC | Yes |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Server |
| PCI Express slots version | 3.0 |
| PCI Express configurations | 1x16+1x4, 1x8+3x4, 2x8+1x4 |
| Supported instruction sets | AVX, SSE4.1, SSE4.2 |
| CPU configuration (max) | 1 |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Fast Memory Access | Yes |
| Intel Flex Memory Access | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Smart Cache | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel Demand Based Switching | Yes |
| Intel Enhanced Halt State | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® vPro™ Platform Eligibility | Yes |
Other features
| Specification | Value |
|---|---|
| Intel® Virtualization Technology (Intel® VT) | VT-d, VT-x |
