Intel Xeon Max 9470
Model Intel Xeon Max 9470Part no. 338-CLMD
61 specifications Checked today
- ProcessorIntel® Xeon® CPU Max
- GraphicsNot available
- Processor manufacturerIntel
- Maximum internal memory supported by processor4 TB
- Discrete graphics cardNo
- Execute Disable BitYes
Overview
- Processor
- Intel® Xeon® CPU Max
- Graphics
- Not available
- Processor manufacturer
- Intel
- Maximum internal memory supported by processor
- 4 TB
- Discrete graphics card
- No
- Execute Disable Bit
- Yes
- Brand
- Dell
- Category
- CPU
- Model
- Intel Xeon Max 9470
- Part number
- 338-CLMD
- Also known as
- DELL Intel Xeon Max 9470 processor 2 GHz 105 MB Tray
Specifications
61 specifications in 8 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® CPU Max |
| Processor model | 9470 |
| Processor base frequency | 2 GHz |
| Processor cores | 52 |
| Processor socket | LGA 4677 (Socket E) |
| Package type | Tray |
| Processor threads | 104 |
| System bus rate | 16 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.5 GHz |
| Processor cache | 105 MB |
| Thermal Design Power (TDP) | 350 W |
| Stepping | B3 |
| Processor codename | Sapphire Rapids HBM |
| Processor ARK ID | 232594 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 4 TB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory channels | Octa-channel |
| ECC | Yes |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | No |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Market segment | Server |
| Maximum number of PCI Express lanes | 80 |
| PCI Express slots version | 5.0 |
| Supported instruction sets | AMX, SSE4.2, AVX, AVX 2.0, AVX-512 |
| Embedded options available | No |
| Scalability | 2S |
Processor special features
| Specification | Value |
|---|---|
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® Total Memory Encryption | Yes |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Intel® Crypto Acceleration | Yes |
| Intel® Platform Firmware Resilience Support | Yes |
| Maximum Enclave Size Support for Intel® SGX | 512 GB |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel 64 | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Boot Guard | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® OS Guard | Yes |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Intel® Run Sure Technology | Yes |
| Intel® Speed Select technology - Performance Profile (Intel® SST-PP) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Data Streaming Accelerator (DSA) | 4 default devices |
| Intel® Advanced Matrix Extensions (AMX) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| DTS Max | 83 °C |
| Tcase | 64 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Processor package size | 100 x 56.5 mm |
Other features
| Specification | Value |
|---|---|
| Compatibility | PowerEdge C6620 PowerEdge R660 PowerEdge R760 |
