Dell Intel Xeon Gold 6140M
Model Intel Xeon Gold 6140MPart no. 338-BLUCEAN 5397184035573
53 specifications Checked 2 days ago
- ProcessorIntel® Xeon® Gold
- Maximum internal memory supported by processor1.46 TB
- Discrete graphics cardNo
- Execute Disable BitYes
- Tcase91 °C
- Number of UPI links3
Overview
- Processor
- Intel® Xeon® Gold
- Maximum internal memory supported by processor
- 1.46 TB
- Discrete graphics card
- No
- Execute Disable Bit
- Yes
- Tcase
- 91 °C
- Number of UPI links
- 3
- Brand
- Dell
- Category
- CPU
- Model
- Intel Xeon Gold 6140M
- Part numbers
- 338-BLUC, 338-BLUE
- EAN / UPC
- 5397184035573, 5711783922247, 5397184035597
- Also known as
- DELL Intel Xeon Gold 6140M processor 2.3 GHz 24.75 MB L3
Specifications
53 specifications in 8 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Xeon® Gold |
| Processor model | 6140M |
| Processor base frequency | 2.3 GHz |
| Processor cores | 18 |
| Processor socket | LGA 3647 (Socket P) |
| Processor lithography | 14 nm |
| Cooler included | No |
| Component for | Server/workstation |
| Processor series | Intel Xeon Gold 6000 Series |
| Processor threads | 36 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.7 GHz |
| Processor cache | 24.75 MB |
| Processor cache type | L3 |
| Thermal Design Power (TDP) | 140 W |
| Stepping | H0 |
| Bus type | UPI |
| Processor codename | Skylake |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 1.46 TB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2666 MHz |
| Memory channels | Hexa-channel |
| ECC | Yes |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | No |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Market segment | Server |
| Maximum number of PCI Express lanes | 48 |
| PCI Express slots version | 3.0 |
| Supported instruction sets | AVX, AVX 2.0, AVX-512, SSE4.2 |
| Embedded options available | No |
| Scalability | S4S |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel 64 | Yes |
| Intel TSX-NI | Yes |
| Intel Turbo Boost Max Technology 3.0 | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Optane™ Memory Ready | No |
| Intel® vPro™ Platform Eligibility | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tcase | 91 °C |
Technical details
| Specification | Value |
|---|---|
| Intel® Run Sure Technology version | Yes |
| Intel® Volume Management Device (VMD) version | Yes |
| Mode-based Execute Control (MBE) version | Yes |
| Number of UPI links | 3 |
Other features
| Specification | Value |
|---|---|
| Compatibility | PowerEdge C4140 PowerEdge C6420 PowerEdge FC640 PowerEdge M640 PowerEdge M640 VRTX PowerEdge R640 PowerEdge R740 PowerEdge R740XD PowerEdge R840 PowerEdge R940 PowerEdge R940xa PowerEdge T640 |
