Dell Intel Xeon E5-4617

Model Intel Xeon E5-4617Part no. 374-14604

72 specifications Checked 4 days ago

Overview

Brand: Dell
Category: CPU
Model: Intel Xeon E5-4617
Part number: 374-14604
Also known as: DELL Xeon Intel E5-4617 processor 2.9 GHz 15 MB Smart Cache Tray

72 specifications in 6 groups

Specification	Value
Processor family	Intel® Xeon® E5 Family
Processor model	E5-4617
Processor base frequency	2.9 GHz
Processor cores	6
Processor socket	LGA 2011 (Socket R)
Processor lithography	32 nm
Package type	Tray
Component for	Server/workstation
Processor series	Intel Xeon E5-4600
Processor threads	6
System bus rate	7.2 GT/s
Processor operating modes	64-bit
Processor boost frequency	3.4 GHz
Processor cache	15 MB
Processor cache type	Smart Cache
L3 cache speed	2.9 GHz
Thermal Design Power (TDP)	130 W
VID Voltage Range	0.60 - 1.35 V
FSB Parity	No
Stepping	C2
Bus type	QPI
Number of QPI links	2
Memory bandwidth supported by processor (max)	51.2 GB/s
Processor codename	Sandy Bridge EP
Processor code	SR0L5

Specification	Value
Maximum internal memory supported by processor	1.5 TB
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	800,1066,1333,1600 MHz
Memory channels	Quad-channel
ECC	Yes

Specification	Value
Execute Disable Bit	Yes
Idle States	Yes
Thermal Monitoring Technologies	Yes
Market segment	Server
Maximum number of PCI Express lanes	40
PCI Express slots version	3.0
Supported instruction sets	AVX
CPU configuration (max)	4
Embedded options available	No
Scalability	S4S

Specification	Value
Enhanced Intel SpeedStep Technology	Yes
Intel Dual Display Capable Technology	No
Intel FDI Technology	No
Intel Fast Memory Access	No
Intel Flex Memory Access	Yes
Intel Trusted Execution Technology	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Smart Cache	Yes
Intel® Turbo Boost Technology	2.0
Intel® Wireless Display (Intel® WiDi)	No
Conflict-Free processor	No
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	Yes
Intel Enhanced Halt State	Yes
Intel Identity Protection Technology version	0.00
Intel Rapid Storage Technology	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	1
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® vPro™ Platform Eligibility	Yes

Specification	Value
Processor cache	15360 KB
Product type	4

Specification	Value
Processor package size	52.5 mm
