Dell Intel Xeon E5-2630 v3 Specs

Overview

Brand: Dell
Category: CPU
Model: Intel Xeon E5-2630 v3
Part numbers: 338-BGZU, 338-BFCU, 338-BHJW, 338-BGOJ, 02524M, 338-BGMD
EAN / UPC: 5711783356219, 5054629668979, 5397063818808, 5397063853113 +2 more
Also known as: DELL Intel Xeon E5-2630 v3 processor 2.4 GHz 20 MB L3

55 specifications in 8 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Xeon E5 v3
Processor model	E5-2630V3
Processor base frequency	2.4 GHz
Processor cores	8
Processor socket	LGA 2011-v3
Processor lithography	22 nm
Component for	Server/workstation
Processor threads	16
System bus rate	8 GT/s
Processor operating modes	64-bit
Processor boost frequency	3.2 GHz
Processor cache	20 MB
Processor cache type	L3
L3 cache speed	2.4 GHz
Thermal Design Power (TDP)	85 W
VID Voltage Range	0.65 - 1.3 V
Stepping	R2
Bus type	QPI
Number of QPI links	2
Memory bandwidth supported by processor (max)	59 GB/s

Specification	Value
Maximum internal memory supported by processor	768 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	1600,1866 MHz
Memory channels	Quad-channel
ECC	Yes

Specification	Value
On-board graphics card	No

Specification	Value
Execute Disable Bit	Yes
Idle States	Yes
Thermal Monitoring Technologies	Yes
Market segment	Server
Maximum number of PCI Express lanes	40
PCI Express slots version	3.0
Supported instruction sets	AVX 2.0
CPU configuration (max)	2
Embedded options available	Yes
Physical Address Extension (PAE)	Yes
Scalability	2S

Specification	Value
Enhanced Intel SpeedStep Technology	Yes
Intel Trusted Execution Technology	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Smart Cache	Yes
Intel® Turbo Boost Technology	2.0
Intel Demand Based Switching	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Intel® vPro™ Platform Eligibility	Yes

Specification	Value
Tcase	72.1 °C

Specification	Value
Processor package size	52.5 mm

Specification	Value
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
Compatibility	PowerEdge R430 PowerEdge R530 PowerEdge R630 PowerEdge R730 PowerEdge R730XD PowerEdge T430 PowerEdge T630
