Dell Intel Xeon E3-1225V5

Model Intel Xeon E3-1225V5Part no. 338-BIKDEAN 5397063826353

73 specifications Checked 5 days ago

Overview

Brand: Dell
Category: CPU
Model: Intel Xeon E3-1225V5
Part number: 338-BIKD
EAN / UPC: 5397063826353
Also known as: DELL Intel Xeon E3-1225V5 processor 3.3 GHz 8 MB Smart Cache Box

73 specifications in 6 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® E3 v5
Processor model	E3-1225V5
Processor base frequency	3.3 GHz
Processor cores	4
Processor socket	LGA 1151 (Socket H4)
Processor lithography	14 nm
Package type	Box
Component for	Server/workstation
Processor series	Intel Xeon E3-1200 v5
Processor threads	4
System bus rate	8 GT/s
Processor operating modes	64-bit
Processor cache	8 MB
Processor cache type	Smart Cache
Thermal Design Power (TDP)	80 W
Bus type	DMI3
Memory bandwidth supported by processor (max)	34.1 GB/s
Processor codename	Skylake

Specification	Value
Maximum internal memory supported by processor	64 GB
Memory types supported by processor	DDR3-SDRAM, DDR4-SDRAM
Memory clock speeds supported by processor	1333,1600,1866,2133 MHz
Memory voltage supported by processor	1.35 V
Memory channels	Dual-channel
ECC	Yes

Specification	Value
On-board graphics card	Yes
On-board graphics card model	Intel® HD Graphics P530
Maximum on-board graphics card memory	1.7 GB
On-board graphics card outputs supported	DVI, DisplayPort, Embedded DisplayPort (eDP), HDMI
On-board graphics card base frequency	400 MHz
Number of displays supported (on-board graphics)	3
On-board graphics card 4K support	Yes
On-board graphics card DirectX version	12.0
On-board graphics card OpenGL version	4.4
On-board graphics card maximum resolution (DisplayPort)	4096 x 2304 pixels
On-board graphics card maximum resolution (HDMI)	4096 x 2304 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)	4096 x 2304 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)	24 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)	60 Hz

Specification	Value
Execute Disable Bit	Yes
Idle States	Yes
Thermal Monitoring Technologies	Yes
Market segment	Server
Maximum number of PCI Express lanes	16
PCI Express slots version	3.0
PCI Express configurations	1x16, 1x8+2x4, 2x8
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
CPU configuration (max)	1
Embedded options available	Yes
Graphics & IMC lithography	14 nm
Scalability	1S

Specification	Value
Enhanced Intel SpeedStep Technology	Yes
Intel Trusted Execution Technology	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® InTru™ 3D Technology	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Smart Cache	Yes
Intel® Turbo Boost Technology	2.0
Intel® Wireless Display (Intel® WiDi)	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel TSX-NI	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Intel® vPro™ Platform Eligibility	Yes

Specification	Value
Processor package size	37.5 x 37.5 mm
