Intel Xeon E-2456
Model Intel Xeon E-2456Part no. 338-CPMH
60 specifications Checked today
- ProcessorIntel Xeon E
- GraphicsNot available
- Processor manufacturerIntel
- Maximum internal memory supported by processor128 GB
- Discrete graphics cardNo
- Execute Disable BitYes
Overview
- Processor
- Intel Xeon E
- Graphics
- Not available
- Processor manufacturer
- Intel
- Maximum internal memory supported by processor
- 128 GB
- Discrete graphics card
- No
- Execute Disable Bit
- Yes
- Brand
- Dell
- Category
- CPU
- Model
- Intel Xeon E-2456
- Part number
- 338-CPMH
- Also known as
- DELL Intel Xeon E-2456 processor 3.3 GHz 18 MB Tray
Specifications
60 specifications in 7 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Xeon E |
| Processor model | E-2456 |
| Processor base frequency | 3.3 GHz |
| Processor cores | 6 |
| Processor socket | LGA 1700 |
| Package type | Tray |
| Processor threads | 12 |
| System bus rate | 16 GT/s |
| Processor operating modes | 64-bit |
| Performance cores | 6 |
| Processor boost frequency | 5.1 GHz |
| Processor cache | 18 MB |
| Thermal Design Power (TDP) | 80 W |
| Stepping | B0 |
| Maximum number of DMI lanes | 8 |
| Processor codename | Raptor Lake |
| Processor ARK ID | 236188 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 128 GB |
| Memory types supported by processor | DDR5-SDRAM |
| Memory channels | Dual-channel |
| ECC | Yes |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | No |
| On-board graphics card model | Not available |
| Discrete graphics card model | Not available |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Server |
| Maximum number of PCI Express lanes | 20 |
| PCI Express slots version | 5.0 |
| PCI Express configurations | 2x8+1x4, 1x16+1x4 |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Scalability | 1S |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Turbo Boost Technology 2.0 frequency | 5.1 GHz |
| Intel® Transactional Synchronization Extensions | No |
| Intel® Total Memory Encryption | Yes |
| Intel 64 | Yes |
| Intel Turbo Boost Max Technology 3.0 | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Boot Guard | Yes |
| Intel® OS Guard | Yes |
| Intel® Optane™ DC Persistent Memory Supported | No |
| Intel® Secure Key | Yes |
| Intel® Virtualization Technology with Redirect Protection (VT-rp) | Yes |
| Microprocessor PCIe Revision | Gen 5 |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Total Memory Encryption - Multi Key | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tjunction | 100 °C |
Other features
| Specification | Value |
|---|---|
| Compatibility | PowerEdge R260 PowerEdge T160 |
