Intel Xeon E-2388G
Model Intel Xeon E-2388GPart no. 338-CCYR-RFB
72 specifications Checked today
- ProcessorIntel Xeon E
- GraphicsNot available
- Processor manufacturerIntel
- Maximum internal memory supported by processor128 GB
- Discrete graphics cardNo
- Execute Disable BitYes
Overview
- Processor
- Intel Xeon E
- Graphics
- Not available
- Processor manufacturer
- Intel
- Maximum internal memory supported by processor
- 128 GB
- Discrete graphics card
- No
- Execute Disable Bit
- Yes
- Brand
- Dell
- Category
- CPU
- Model
- Intel Xeon E-2388G
- Part numbers
- 338-CCYR-RFB, 338-CCYR
- Also known as
- DELL Intel Xeon E-2388G processor 3.2 GHz 16 MB Smart Cache Tray
Specifications
72 specifications in 9 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Xeon E |
| Processor model | E-2388G |
| Processor base frequency | 3.2 GHz |
| Processor cores | 8 |
| Processor socket | LGA 1200 (Socket H5) |
| Processor lithography | 14 nm |
| Package type | Tray |
| Processor threads | 16 |
| System bus rate | 8 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 5.1 GHz |
| Processor cache | 16 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 95 W |
| Stepping | B0 |
| Processor ARK ID | 214805 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 128 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory channels | Dual-channel |
| ECC | Yes |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | Yes |
| On-board graphics card model | Intel UHD Graphics P750 |
| Maximum on-board graphics card memory | 64 GB |
| On-board graphics card base frequency | 350 MHz |
| On-board graphics card dynamic frequency (max) | 1300 MHz |
| Number of displays supported (on-board graphics) | 1 |
| On-board graphics card 4K support | Yes |
| On-board graphics card DirectX version | 12.1 |
| On-board graphics card OpenGL version | 4.5 |
| On-board graphics card ID | 0x4C9A |
| Discrete graphics card model | Not available |
| Number of execution units | 32 |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Server |
| Use conditions | Server/Enterprise |
| Maximum number of PCI Express lanes | 20 |
| PCI Express slots version | 4.0 |
| Supported instruction sets | AVX-512, SSE4.1, SSE4.2, AVX 2.0 |
| CPU configuration (max) | 1 |
| Embedded options available | No |
| Scalability | 1S |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Clear Video HD Technology (Intel® CVT HD) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel® Turbo Boost Technology 2.0 frequency | 5.1 GHz |
| Intel® Transactional Synchronization Extensions | No |
| Maximum Enclave Size Support for Intel® SGX | 0.5 GB |
| Intel 64 | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Boot Guard | Yes |
| Intel® OS Guard | Yes |
| Intel® Optane™ DC Persistent Memory Supported | No |
| Intel® Secure Key | Yes |
| Microprocessor PCIe Revision | Gen 4 |
| Intel vPro® Enterprise Platform Eligibility | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tjunction | 100 °C |
Technical details
| Specification | Value |
|---|---|
| Launch date | Q3'21 |
| Status | Launched |
| Servicing status | Baseline Servicing |
Weight & dimensions
| Specification | Value |
|---|---|
| Processor package size | 37.5 x 37.5 mm |
Other features
| Specification | Value |
|---|---|
| Maximum internal memory | 128 GB |
