Dell Intel Xeon Bronze 3106
Model Intel Xeon Bronze 3106Part no. 338-BLTQEAN 884116306641
49 specifications Checked 3 days ago
- ProcessorIntel Xeon Bronze
- Processor manufacturerIntel
- Maximum internal memory supported by processor768 GB
- On-board graphics cardNo
- Execute Disable BitYes
- Tcase77 °C
Overview
- Processor
- Intel Xeon Bronze
- Processor manufacturer
- Intel
- Maximum internal memory supported by processor
- 768 GB
- On-board graphics card
- No
- Execute Disable Bit
- Yes
- Tcase
- 77 °C
- Brand
- Dell
- Category
- CPU
- Model
- Intel Xeon Bronze 3106
- Part number
- 338-BLTQ
- EAN / UPC
- 884116306641, 5397184035474
- Also known as
- DELL Intel Xeon Bronze 3106 processor 1.7 GHz 11 MB L3
Specifications
49 specifications in 7 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Xeon Bronze |
| Processor generation | 1st Generation Intel® Xeon® Scalable |
| Processor model | 3106 |
| Processor base frequency | 1.7 GHz |
| Processor cores | 8 |
| Processor socket | LGA 3647 (Socket P) |
| Processor lithography | 14 nm |
| Cooler included | No |
| Component for | Server/workstation |
| Processor series | Intel Xeon Bronze 3000 Series |
| Processor threads | 8 |
| Processor operating modes | 64-bit |
| Processor cache | 11 MB |
| Processor cache type | L3 |
| Thermal Design Power (TDP) | 85 W |
| Stepping | U0 |
| Bus type | UPI |
| Number of QPI links | 2 |
| Processor codename | Skylake |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 768 GB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2133 MHz |
| Memory channels | Hexa-channel |
| ECC | Yes |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Market segment | Server |
| Maximum number of PCI Express lanes | 48 |
| PCI Express slots version | 3.0 |
| Supported instruction sets | AVX, AVX 2.0, AVX-512, SSE4.2 |
| Embedded options available | Yes |
| Scalability | 2S |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Turbo Boost Technology | No |
| Intel 64 | Yes |
| Intel TSX-NI | Yes |
| Intel Turbo Boost Max Technology 3.0 | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Optane™ Memory Ready | No |
| Intel® vPro™ Platform Eligibility | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tcase | 77 °C |
Other features
| Specification | Value |
|---|---|
| Compatibility | PowerEdge R440 PowerEdge T640 PowerEdge T440 PowerEdge FC640 PowerEdge M640 PowerEdge R540 |
