Dell Intel Xeon 5160
Model Intel Xeon 5160Part no. 223-4846
37 specifications Checked yesterday
- ProcessorIntel® Xeon® 5000 Sequence
- ECCNo
- Execute Disable BitYes
- Tcase65 °C
Overview
- Processor
- Intel® Xeon® 5000 Sequence
- ECC
- No
- Execute Disable Bit
- Yes
- Tcase
- 65 °C
- Brand
- Dell
- Category
- CPU
- Model
- Intel Xeon 5160
- Part numbers
- 223-4846, 311-6285, 0CU747, 311-6871, 223-4721, 0HT023 +10 more
- Also known as
- DELL Intel Xeon 5160 processor 3 GHz 4 MB L2
Specifications
37 specifications in 6 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Xeon® 5000 Sequence |
| Processor model | 5160 |
| Processor base frequency | 3 GHz |
| Processor socket | LGA 771 (Socket J) |
| Processor lithography | 65 nm |
| Cooler included | No |
| Component for | Server/workstation |
| Processor series | Intel Xeon 5000 Series |
| Processor operating modes | 64-bit |
| Processor cache | 4 MB |
| Processor cache type | L2 |
| Processor front side bus | 1333 MHz |
| Thermal Design Power (TDP) | 80 W |
| VID Voltage Range | 0.85 - 1.5 V |
| FSB Parity | Yes |
| Stepping | B2 |
Memory
| Specification | Value |
|---|---|
| ECC | No |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | No |
| On-board graphics card | No |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Server |
| Number of Processing Die Transistors | 291 M |
| Processing Die size | 143 mm² |
| Embedded options available | No |
| Physical Address Extension (PAE) | 32 bit |
| Physical Address Extension (PAE) | Yes |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Turbo Boost Technology | No |
| Intel 64 | Yes |
| Intel Demand Based Switching | No |
| Intel VT-x with Extended Page Tables (EPT) | No |
| Intel Virtualization Technology (VT-x) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tcase | 65 °C |
