Dell i5-750 processor
2.66 GHz 8 MB Smart Cache
Model i5-750Part no. 11C4W
56 specifications Checked 3 days ago
- ProcessorIntel® Core™ i3
- Maximum internal memory supported by processor16 GB
- On-board graphics cardNo
- Execute Disable BitYes
- Tcase72.7 °C
- Processor cache8192 KB
Overview
- Processor
- Intel® Core™ i3
- Maximum internal memory supported by processor
- 16 GB
- On-board graphics card
- No
- Execute Disable Bit
- Yes
- Tcase
- 72.7 °C
- Processor cache
- 8192 KB
- Brand
- Dell
- Category
- CPU
- Model
- i5-750
- Part number
- 11C4W
- Also known as
- DELL i5-750 processor 2.66 GHz 8 MB Smart Cache
Specifications
56 specifications in 9 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Core™ i3 |
| Processor generation | 5th gen Intel® Core™ i3 |
| Processor model | i5-750 |
| Processor base frequency | 2.66 GHz |
| Processor cores | 4 |
| Processor socket | LGA 1156 (Socket H) |
| Processor lithography | 45 nm |
| Component for | PC |
| Processor series | Intel Core i5-700 Desktop Series |
| Processor threads | 4 |
| System bus rate | 2.5 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.2 GHz |
| Processor cache | 8 MB |
| Processor cache type | Smart Cache |
| Thermal Design Power (TDP) | 95 W |
| VID Voltage Range | 0.65 - 1.4 V |
| Compatible chipsets | Intel® H55 Express, Intel® H57 Express, Intel® Q57 Express |
| Stepping | B1 |
| Bus type | DMI |
| CPU multiplier (bus/core ratio) | 20 |
| Memory bandwidth supported by processor (max) | 21 GB/s |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 16 GB |
| Memory types supported by processor | DDR3-SDRAM |
| Memory clock speeds supported by processor | 1066,1333 MHz |
| Memory channels | Dual-channel |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Thermal Monitoring Technologies | No |
| Market segment | Desktop |
| Maximum number of PCI Express lanes | 16 |
| PCI Express slots version | 2.0 |
| PCI Express configurations | 1x16, 2x8 |
| Number of Processing Die Transistors | 774 M |
| Processing Die size | 296 mm² |
| Number of Graphics & IMC Die Transistors | 774 M |
| Supported instruction sets | SSE4.2 |
| CPU configuration (max) | 1 |
| Embedded options available | Yes |
| Physical Address Extension (PAE) | 36 bit |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | No |
| Intel® AES New Instructions (Intel® AES-NI) | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® Turbo Boost Technology | Yes |
| Conflict-Free processor | No |
| Intel 64 | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® vPro™ Platform Eligibility | No |
Operational conditions
| Specification | Value |
|---|---|
| Tcase | 72.7 °C |
Technical details
| Specification | Value |
|---|---|
| Processor cache | 8192 KB |
Weight & dimensions
| Specification | Value |
|---|---|
| Processor package size | 37.5 x 37.5 mm |
Other features
| Specification | Value |
|---|---|
| Intel® Virtualization Technology (Intel® VT) | VT-x |
