Dell 2 x Intel Xeon E7-4860
Model 2 x Intel Xeon E7-4860Part no. 338-BFMXEAN 5397063837953
42 specifications Checked 4 days ago
- ProcessorIntel® Xeon® E7 Family
- Processor manufacturerIntel
- Maximum internal memory supported by processor2 TB
- On-board graphics cardNo
- Execute Disable BitYes
- Tcase69 °C
Overview
- Processor
- Intel® Xeon® E7 Family
- Processor manufacturer
- Intel
- Maximum internal memory supported by processor
- 2 TB
- On-board graphics card
- No
- Execute Disable Bit
- Yes
- Tcase
- 69 °C
- Brand
- Dell
- Category
- CPU
- Model
- 2 x Intel Xeon E7-4860
- Part number
- 338-BFMX
- EAN / UPC
- 5397063837953
- Also known as
- DELL 2 x Intel Xeon E7-4860 processor 2.26 GHz 24 MB L3
Specifications
42 specifications in 8 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® E7 Family |
| Processor model | E7-4860 |
| Processor base frequency | 2.26 GHz |
| Processor cores | 10 |
| Processor socket | LGA 1567 (Socket LS) |
| Processor lithography | 32 nm |
| Component for | Server/workstation |
| Processor threads | 20 |
| System bus rate | 6.4 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 2.666 GHz |
| Processor cache | 24 MB |
| Processor cache type | L3 |
| Thermal Design Power (TDP) | 130 W |
| Compatible chipsets | Intel® 7500 |
| Stepping | A2 |
| CPU multiplier (bus/core ratio) | 17 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 2 TB |
| Memory types supported by processor | DDR3-SDRAM |
| Memory clock speeds supported by processor | 800,978,1066,1333 MHz |
| Memory channels | Quad-channel |
| ECC | Yes |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
Features
| Specification | Value |
|---|---|
| Execute Disable Bit | Yes |
| Thermal Monitoring Technologies | Yes |
| Market segment | Server |
| Supported instruction sets | SSE4.1, SSE4.2 |
| CPU configuration (max) | 4 |
| Scalability | S4S |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Tcase | 69 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Processor package size | 49.17 mm |
Other features
| Specification | Value |
|---|---|
| Intel® Virtualization Technology (Intel® VT) | VT-d, VT-x |
| Compatibility | PowerEdge R430 PowerEdge R530 PowerEdge R630 PowerEdge R730 PowerEdge R730XD PowerEdge T630 |
