Acer Intel Xeon X5650
Model Intel Xeon X5650Part no. TC.32500.022EAN 884483882694
29 specifications Checked 4 days ago
- ProcessorIntel® Xeon® 5000 Sequence
- Maximum internal memory supported by processor288 GB
- Market segmentServer
- Maximum operating temperature81.3 °C
- Package dimensions (WxDxH)42.5 x 42.5 x 45 mm
Overview
- Processor
- Intel® Xeon® 5000 Sequence
- Maximum internal memory supported by processor
- 288 GB
- Market segment
- Server
- Maximum operating temperature
- 81.3 °C
- Package dimensions (WxDxH)
- 42.5 x 42.5 x 45 mm
- Brand
- Acer
- Category
- CPU
- Model
- Intel Xeon X5650
- Part numbers
- TC.32500.022, KC.55601.EPX, KC.56501.EPX
- EAN / UPC
- 884483882694, 8844838826942
- Also known as
- Acer Intel Xeon X5650 processor 2.66 GHz 12 MB L3 Tray
Specifications
29 specifications in 6 groups
Processor
| Specification | Value |
|---|---|
| Processor family | Intel® Xeon® 5000 Sequence |
| Processor model | X5650 |
| Processor base frequency | 2.66 GHz |
| Processor cores | 6 |
| Processor socket | Socket B (LGA 1366) |
| Processor lithography | 32 nm |
| Package type | Tray |
| Component for | Server/workstation |
| Processor threads | 12 |
| System bus rate | 6.4 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 3.06 GHz |
| Processor cache | 12 MB |
| Processor cache type | L3 |
| Thermal Design Power (TDP) | 95 W |
| VID Voltage Range | 0.750 - 1.350 V |
| Stepping | B1 |
| CPU multiplier (bus/core ratio) | 20 |
| Memory bandwidth supported by processor (max) | 32 GB/s |
| Processor system type | DP |
| Processor code | SLBV3 |
Memory
| Specification | Value |
|---|---|
| Maximum internal memory supported by processor | 288 GB |
| Memory clock speeds supported by processor | 800,1066,1333 MHz |
| Memory channels | Triple-channel |
| ECC | Yes |
Features
| Specification | Value |
|---|---|
| Market segment | Server |
Operational conditions
| Specification | Value |
|---|---|
| Maximum operating temperature | 81.3 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Package dimensions (WxDxH) | 42.5 x 42.5 x 45 mm |
Other features
| Specification | Value |
|---|---|
| On-board memory controller | Yes |
