Intel Pentium Gold G6400T

Model Intel Pentium Gold G6400TPart no. KC.64001.DET

78 specifications Checked today

Overview

Brand: Acer
Category: CPU
Model: Intel Pentium Gold G6400T
Part number: KC.64001.DET
Also known as: Acer Intel Pentium Gold G6400T processor 3.4 GHz 4 MB Smart Cache

78 specifications in 6 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Pentium® Gold
Processor model	G6400T
Processor base frequency	3.4 GHz
Processor cores	2
Processor socket	LGA 1200 (Socket H5)
Processor lithography	14 nm
Component for	PC
Processor threads	4
System bus rate	8 GT/s
Processor operating modes	64-bit
Processor cache	4 MB
Processor cache type	Smart Cache
Thermal Design Power (TDP)	35 W
Configurable TDP-down frequency	2.3 GHz
Configurable TDP-down	25 W
Memory bandwidth supported by processor (max)	41.6 GB/s
Processor codename	Comet Lake

Specification	Value
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2666 MHz
Memory channels	Dual-channel
ECC	No

Specification	Value
Discrete graphics card	No
On-board graphics card	Yes
On-board graphics card model	Intel® UHD Graphics 610
Maximum on-board graphics card memory	64 GB
On-board graphics card base frequency	350 MHz
On-board graphics card dynamic frequency (max)	1050 MHz
Number of displays supported (on-board graphics)	3
On-board graphics card 4K support	Yes
On-board graphics card DirectX version	12.0
On-board graphics card OpenGL version	4.5
On-board graphics card maximum resolution (DisplayPort)	4096 x 2304 pixels
On-board graphics card maximum resolution (HDMI)	4096 x 2160 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)	4096 x 2304 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)	30 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)	60 Hz
Discrete graphics card model	Not available

Specification	Value
Execute Disable Bit	Yes
Idle States	Yes
Thermal Monitoring Technologies	Yes
Market segment	Desktop
Maximum number of PCI Express lanes	16
PCI Express slots version	3.0
PCI Express configurations	1x16, 1x8+2x4, 2x8
Supported instruction sets	SSE4.1, SSE4.2
CPU configuration (max)	1
Embedded options available	No
PCI Express CEM revision	3.0
Scalability	1S
Thermal solution specification	PCG 2015B

Specification	Value
Enhanced Intel SpeedStep Technology	Yes
Intel Trusted Execution Technology	No
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Turbo Boost Technology	No
Intel® Thermal Velocity Boost	No
Intel® Transactional Synchronization Extensions	No
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel Stable Image Platform Program (SIPP)	No
Intel Turbo Boost Max Technology 3.0	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® Boot Guard	Yes
Intel® OS Guard	Yes
Intel® Optane™ Memory Ready	Yes
Intel® Secure Key	Yes
Intel® vPro™ Platform Eligibility	No

Specification	Value
Tjunction	100 °C
