I9-10900X processor

3.7 GHz 19.25 MB Smart Cache Tray

Model I9-10900XPart no. KC.09001.XI9

65 specifications Checked today

Overview

65 specifications in 9 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i9 X-series
Processor generation	10th gen Intel® Core™ i9
Processor model	i9-10900X
Processor base frequency	3.7 GHz
Processor cores	10
Processor socket	LGA 2066 (Socket R4)
Processor lithography	14 nm
Package type	Tray
Cooler included	No
Component for	PC
Processor threads	20
System bus rate	8 GT/s
Processor operating modes	64-bit
Processor boost frequency	4.5 GHz
Processor cache	19.25 MB
Processor cache type	Smart Cache
Thermal Design Power (TDP)	165 W
Memory bandwidth supported by processor (max)	94 GB/s
Processor codename	Cascade Lake
Processor ARK ID	198019
Generation	10th Generation

Specification	Value
Maximum internal memory supported by processor	256 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2933 MHz
Memory channels	Quad-channel
ECC	No

Specification	Value
Discrete graphics card	No
On-board graphics card	No
On-board graphics card model	Not available
Discrete graphics card model	Not available

Specification	Value
Execute Disable Bit	Yes
Market segment	Desktop
Maximum number of PCI Express lanes	48
PCI Express slots version	3.0
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0, AVX-512
CPU configuration (max)	1
Embedded options available	No
PCI Express CEM revision	3.0
Scalability	1S
Thermal solution specification	PCG 2017X
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	G077159

Specification	Value
Enhanced Intel SpeedStep Technology	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	2.0
Intel® Turbo Boost Max Technology 3.0 frequency	4.7 GHz
AVX-512 Fused Multiply-Add (FMA) units	2
Intel 64	Yes
Intel Turbo Boost Max Technology 3.0	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU	Yes
Intel® Optane™ Memory Ready	Yes

Specification	Value
Tjunction	94 °C
