i5-11500 processor

2.7 GHz 12 MB Smart Cache Tray

Model i5-11500Part no. KC.11501.CI5

83 specifications Checked today

Overview

83 specifications in 7 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i5
Processor generation	11th gen Intel® Core™ i5
Processor model	i5-11500
Processor base frequency	2.7 GHz
Processor cores	6
Processor socket	LGA 1200 (Socket H5)
Processor lithography	14 nm
Package type	Tray
Cooler included	No
Processor threads	12
System bus rate	8 GT/s
Processor operating modes	64-bit
Processor boost frequency	4.6 GHz
Processor cache	12 MB
Processor cache type	Smart Cache
Thermal Design Power (TDP)	65 W
Memory bandwidth supported by processor (max)	50 GB/s
Processor ARK ID	212277

Specification	Value
Maximum internal memory supported by processor	128 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	3200 MHz
Memory channels	Dual-channel
ECC	No
Memory bandwidth (max)	50 GB/s

Specification	Value
Discrete graphics card	No
On-board graphics card	Yes
On-board graphics card model	Intel UHD Graphics 750
Maximum on-board graphics card memory	64 GB
On-board graphics card base frequency	350 MHz
On-board graphics card dynamic frequency (max)	1300 MHz
Number of displays supported (on-board graphics)	3
On-board graphics card 4K support	Yes
On-board graphics card OpenGL version	4.5
On-board graphics card maximum resolution (DisplayPort)	5120 x 3200 pixels
On-board graphics card maximum resolution (HDMI)	4096 x 2160 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel)	5120 x 3200 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)	60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)	60 Hz
On-board graphics card ID	0x4C8A
Discrete graphics card model	Not available
Number of execution units	32

Specification	Value
Execute Disable Bit	Yes
Idle States	Yes
Thermal Monitoring Technologies	Yes
Market segment	Desktop
Use conditions	PC/Client/Tablet
Maximum number of PCI Express lanes	20
PCI Express slots version	4.0
PCI Express configurations	1x16+1x4, 2x8+1x4, 1x8+3x4
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0, AVX-512
CPU configuration (max)	1
Embedded options available	No
Scalability	1S

Specification	Value
Enhanced Intel SpeedStep Technology	Yes
Intel Trusted Execution Technology	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Quick Sync Video Technology	Yes
Intel® Turbo Boost Technology	2.0
Intel® Thermal Velocity Boost	No
Intel® Turbo Boost Technology 2.0 frequency	4.6 GHz
Intel® Gaussian & Neural Accelerator (Intel® GNA) 2.0	Yes
Intel 64	Yes
Intel Clear Video Technology	Yes
Intel Software Guard Extensions (Intel SGX)	No
Intel Stable Image Platform Program (SIPP)	Yes
Intel Turbo Boost Max Technology 3.0	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® Boot Guard	Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU	Yes
Intel® OS Guard	Yes
Intel® Optane™ Memory Ready	Yes
Intel® Secure Key	Yes
Intel® vPro™ Platform Eligibility	Yes

Specification	Value
Tjunction	100 °C

Specification	Value
Processor package size	37.5 x 37.5 mm
