CM8116-10G-USB console server RS-232/RJ-45
Model CM8116-10G-USBEAN 843295107555
38 specifications
- ProcessorMarvell
- Memory2000 MB
- Weight3.5 kg
- ColourBlack, Red
- Mobile network generation5G
- Security algorithmsIPSec, SNMP, SSH
Overview
- Processor
- Marvell
- Memory
- 2000 MB
- Weight
- 3.5 kg
- Colour
- Black, Red
- Mobile network generation
- 5G
- Security algorithms
- IPSec, SNMP, SSH
- Brand
- Opengear
- Category
- Console Server
- Model
- CM8116-10G-USB
- Part number
- CM8116-10G-USB
- EAN / UPC
- 843295107555
- Also known as
- Opengear CM8116-10G-USB console server RS-232/RJ-45
Specifications
38 specifications in 10 groups
Features
| Specification | Value |
|---|---|
| Mobile network generation | 5G |
| Cooling type | Passive |
| Cellular | Yes |
| MIB support | Yes |
| Product colour | Black, Red |
| Rack mounting | Yes |
| Supported programming languages | Perl, Python |
| Temperature sensor | Yes |
| Web-based management | Yes |
| Zero Touch Provisioning (ZTP) | Yes |
Security
| Specification | Value |
|---|---|
| Security algorithms | IPSec, SNMP, SSH |
| Authentication method | TACACS+, RADIUS, OpenLDAP |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
Ports & interfaces
| Specification | Value |
|---|---|
| Console port | RS-232/RJ-45 |
| Serial ports quantity | 16 |
| USB 2.0 ports quantity | 8 |
| Ethernet LAN (RJ-45) ports | 2 |
| AC outlet types | C14 coupler |
Processor
| Specification | Value |
|---|---|
| Processor family | Marvell |
| Processor architecture | ARM Cortex-A9 |
| Processor cores | 2 |
| Processor frequency | 1600 MHz |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Number of power supply units | 2 |
Network
| Specification | Value |
|---|---|
| Copper ethernet cabling technology | 10BASE-T, 100BASE-T, 1000BASE-T |
Memory
| Specification | Value |
|---|---|
| Flash memory | 32000 MB |
| Internal memory | 2000 MB |
| RAM type | DDR4 |
| eMMC capacity | 32 GB |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | 5 - 50 °C |
| Storage temperature (T-T) | -30 - 60 °C |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 440 x 265 x 44 mm |
| Weight | 3.5 kg |
