SN0148 console server
Model SN0148EAN 672792401787
13 specifications
- Weight492 g
- Rack mountingYes
- USB 2.0 ports quantity3
- Power source typeAC
- Operating relative humidity (H-H)0 - 80%
- Dimensions (WxDxH)327 x 438 x 44 mm
Overview
- Weight
- 492 g
- Rack mounting
- Yes
- USB 2.0 ports quantity
- 3
- Power source type
- AC
- Operating relative humidity (H-H)
- 0 - 80%
- Dimensions (WxDxH)
- 327 x 438 x 44 mm
- Brand
- ATEN
- Category
- Console Server
- Model
- SN0148
- Part number
- SN0148
- EAN / UPC
- 672792401787, 6727924017870
- Also known as
- ATEN SN0148 console server
Specifications
13 specifications in 5 groups
Features
| Specification | Value |
|---|---|
| Rack mounting | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 48 |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (typical) | 42 W |
| Input current | 1.8 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 80% |
| Operating temperature (T-T) | 0 - 50 °C |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 327 x 438 x 44 mm |
| Weight | 492 g |
