SN0132CO-AXA-G console server RJ-45/Mini-USB
Model SN0132CO-AXA-G
20 specifications
- Weight5.65 kg
- ColourBlack
- Console portRJ-45/Mini-USB
- Power source typeAC
- Operating relative humidity (H-H)0 - 80%
- Dimensions (WxDxH)327.7 x 438.4 x 44 mm
Overview
- Weight
- 5.65 kg
- Colour
- Black
- Console port
- RJ-45/Mini-USB
- Power source type
- AC
- Operating relative humidity (H-H)
- 0 - 80%
- Dimensions (WxDxH)
- 327.7 x 438.4 x 44 mm
- Brand
- ATEN
- Category
- Console Server
- Model
- SN0132CO-AXA-G
- Part number
- SN0132CO-AXA-G
- Also known as
- ATEN SN0132CO-AXA-G console server RJ-45/Mini-USB
Specifications
20 specifications in 6 groups
Features
| Specification | Value |
|---|---|
| Product colour | Black |
Ports & interfaces
| Specification | Value |
|---|---|
| Console port | RJ-45/Mini-USB |
| Serial ports quantity | 32 |
| USB 2.0 ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 2 |
Power
| Specification | Value |
|---|---|
| Power source type | AC |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 / 60 Hz |
| Input current | 1 A |
Certificates
| Specification | Value |
|---|---|
| Certification | RoHS |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 0 - 80% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage relative humidity (H-H) | 0 - 80% |
| Storage temperature (T-T) | -20 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 327.7 x 438.4 x 44 mm |
| Package depth | 575 mm |
| Package height | 130 mm |
| Package weight | 6.64 kg |
| Package width | 453 mm |
| Weight | 5.65 kg |
