Product comparison · 2 wireless access points

NETGEAR Insight Cloud Managed WiFi 6 AX1800 Dual Band Access Point (WAX610) vs NETGEAR Insight Cloud Managed WiFi 6 AX1800 Dual Band Outdoor Access Point (WAX610Y)

35specifications compared
14differ
21identical
12known for one product only

Key differences

The NETGEAR Insight Cloud Managed WiFi 6 AX1800 Dual Band Access Point (WAX610) has 10,000 ,1000,2500 Mbit/s more Ethernet LAN data rates than the NETGEAR Insight Cloud Managed WiFi 6 AX1800 Dual Band Outdoor Access Point (WAX610Y) (10,100,1000,2500 Mbit/s vs 100,1000,2500 Mbit/s). The NETGEAR Insight Cloud Managed WiFi 6 AX1800 Dual Band Outdoor Access Point (WAX610Y) has 20.1 mm more width than the NETGEAR Insight Cloud Managed WiFi 6 AX1800 Dual Band Access Point (WAX610) (181 mm vs 160.9 mm). The NETGEAR Insight Cloud Managed WiFi 6 AX1800 Dual Band Outdoor Access Point (WAX610Y) has 144.1 mm more depth than the NETGEAR Insight Cloud Managed WiFi 6 AX1800 Dual Band Access Point (WAX610) (305 mm vs 160.9 mm). Placement: Ceiling, Wall on the NETGEAR Insight Cloud Managed WiFi 6 AX1800 Dual Band Access Point (WAX610), Ceiling, Pole, Wall on the NETGEAR Insight Cloud Managed WiFi 6 AX1800 Dual Band Outdoor Access Point (WAX610Y). LED indicators: LAN, Power, Status on the NETGEAR Insight Cloud Managed WiFi 6 AX1800 Dual Band Access Point (WAX610), LAN, Power, WLAN on the NETGEAR Insight Cloud Managed WiFi 6 AX1800 Dual Band Outdoor Access Point (WAX610Y).

Ethernet LAN data rates
- Insight Cloud Managed WiFi 6 AX1800 Dual Band Access Point (WAX610):10,100,1000,2500 Mbit/s
- Insight Cloud Managed WiFi 6 AX1800 Dual Band Outdoor Access Point (WAX610Y):100,1000,2500 Mbit/s
Placement
- Insight Cloud Managed WiFi 6 AX1800 Dual Band Access Point (WAX610):Ceiling, Wall
- Insight Cloud Managed WiFi 6 AX1800 Dual Band Outdoor Access Point (WAX610Y):Ceiling, Pole, Wall
LED indicators
- Insight Cloud Managed WiFi 6 AX1800 Dual Band Access Point (WAX610):LAN, Power, Status
- Insight Cloud Managed WiFi 6 AX1800 Dual Band Outdoor Access Point (WAX610Y):LAN, Power, WLAN
Width
- Insight Cloud Managed WiFi 6 AX1800 Dual Band Access Point (WAX610):160.9 mm
- Insight Cloud Managed WiFi 6 AX1800 Dual Band Outdoor Access Point (WAX610Y):181 mm
Depth
- Insight Cloud Managed WiFi 6 AX1800 Dual Band Access Point (WAX610):160.9 mm
- Insight Cloud Managed WiFi 6 AX1800 Dual Band Outdoor Access Point (WAX610Y):305 mm
Height
- Insight Cloud Managed WiFi 6 AX1800 Dual Band Access Point (WAX610):33.2 mm
- Insight Cloud Managed WiFi 6 AX1800 Dual Band Outdoor Access Point (WAX610Y):34 mm
Weight
- Insight Cloud Managed WiFi 6 AX1800 Dual Band Access Point (WAX610):412 g
- Insight Cloud Managed WiFi 6 AX1800 Dual Band Outdoor Access Point (WAX610Y):940 g
Package width
- Insight Cloud Managed WiFi 6 AX1800 Dual Band Access Point (WAX610):220 mm
- Insight Cloud Managed WiFi 6 AX1800 Dual Band Outdoor Access Point (WAX610Y):390 mm

Side by side

Differences highlightedShow differences only

Comparison of Insight Cloud Managed WiFi 6 AX1800 Dual Band Access Point (WAX610), Insight Cloud Managed WiFi 6 AX1800 Dual Band Outdoor Access Point (WAX610Y)
47 specifications	A NETGEAR Insight Cloud Managed WiFi 6 AX1800 Dual Band Access Point (WAX610)View product	B NETGEAR Insight Cloud Managed WiFi 6 AX1800 Dual Band Outdoor Access Point (WAX610Y)View product
Features2 differ
Ethernet LAN data ratesDiffers	10,100,1000,2500 Mbit/s	100,1000,2500 Mbit/s
Networking standardsDiffers	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at	IEEE 802.11ax, IEEE 802.3af, IEEE 802.3at
Number of usersKnown for one	250 user(s)	Unknown — not stated by the source
Adaptive bandwidth managementKnown for one	Unknown — not stated by the source	Yes
Security1 differ
Security algorithmsDiffers	EAP-PEAP, EAP-TLS, EAP-TTLS, PEAP, SSH, SSL/TLS, WPA, WPA2, WPA2-Enterprise, WPA3	EAP-PEAP, EAP-TLS, EAP-TTLS, PEAP, SSID, TTLS, WPA, WPA2, WPA3
Service Set Identifier (SSID) featuresKnown for one	Multiple SSIDs, SSID broadcast, SSID broadcast on/off	Unknown — not stated by the source
Number of SSID supportedKnown for one	8	Unknown — not stated by the source
Remote Authentication Dial-In User Service (RADIUS)Known for one	Yes	Unknown — not stated by the source
Ports & interfacesidentical
DC-in jackKnown for one	Yes	Unknown — not stated by the source
Poweridentical
AC input voltageKnown for one	12 V	Unknown — not stated by the source
Input currentKnown for one	2.5 A	Unknown — not stated by the source
Power consumption (typical)Known for one	Unknown — not stated by the source	16.1 W
Design2 differ
PlacementDiffers	Ceiling, Wall	Ceiling, Pole, Wall
Reset buttonKnown for one	Yes	Unknown — not stated by the source
LED indicatorsDiffers	LAN, Power, Status	LAN, Power, WLAN
International Protection (IP) codeKnown for one	Unknown — not stated by the source	IP55
Antennaidentical
Antenna gain level (max)Known for one	4.5 dBi	Unknown — not stated by the source
Weight & dimensions4 differ
WidthDiffers	160.9 mm	181 mm
DepthDiffers	160.9 mm	305 mm
HeightDiffers	33.2 mm	34 mm
WeightDiffers	412 g	940 g
Packaging data4 differ
Package widthDiffers	220 mm	390 mm
Package depthDiffers	455 mm	430 mm
Package heightDiffers	235 mm	350 mm
Package weightDiffers	3.98 kg	11.7 kg
Operational conditions1 differ
Operating temperature (T-T)Differs	0 - 40 °C	-10 - 50 °C

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
