Product comparison · 2 wireless access points

Linksys Dual-Band Wireless A+G Access Point vs Linksys Wireless-G Access Point with SRX

15specifications compared
9differ
6identical
8known for one product only

Key differences

The Linksys Wireless-G Access Point with SRX has 3 dBm more output power description than the Linksys Dual-Band Wireless A+G Access Point (19dBm vs 16 dBm). The Linksys Wireless-G Access Point with SRX has 5 - 90% more storage relative humidity (H-H) than the Linksys Dual-Band Wireless A+G Access Point (10 - 90% vs 5 - 90%). Power requirements: 5V DC, 2.5A on the Linksys Dual-Band Wireless A+G Access Point, 12V DC on the Linksys Wireless-G Access Point with SRX. Certification: FCC on the Linksys Dual-Band Wireless A+G Access Point, FCC, CE, Wi-Fi on the Linksys Wireless-G Access Point with SRX. Dimensions (WxDxH): 186 x 175 x 48 mm on the Linksys Dual-Band Wireless A+G Access Point, 140 x 33 x 140 mm on the Linksys Wireless-G Access Point with SRX.

Power requirements
- Dual-Band Wireless A+G Access Point:5V DC, 2.5A
- Wireless-G Access Point with SRX:12V DC
Output power description
- Dual-Band Wireless A+G Access Point:16 dBm
- Wireless-G Access Point with SRX:19dBm
Certification
- Dual-Band Wireless A+G Access Point:FCC
- Wireless-G Access Point with SRX:FCC, CE, Wi-Fi
Dimensions (WxDxH)
- Dual-Band Wireless A+G Access Point:186 x 175 x 48 mm
- Wireless-G Access Point with SRX:140 x 33 x 140 mm
Networking features
- Dual-Band Wireless A+G Access Point:WLAN, Ethernet LAN
- Wireless-G Access Point with SRX:Ethernet LAN, WLAN
Storage temperature (T-T)
- Dual-Band Wireless A+G Access Point:-20 - 70 °C
- Wireless-G Access Point with SRX:0 - 70 °C
Storage relative humidity (H-H)
- Dual-Band Wireless A+G Access Point:5 - 90%
- Wireless-G Access Point with SRX:10 - 90%

Side by side

Differences highlightedShow differences only

Comparison of Dual-Band Wireless A+G Access Point, Wireless-G Access Point with SRX
23 specifications	A Linksys Dual-Band Wireless A+G Access Point View product	B Linksys Wireless-G Access Point with SRX View product
Featuresidentical
2.4 GHzKnown for one	Yes	Unknown — not stated by the source
5 GHzKnown for one	Yes	Unknown — not stated by the source
Maximum data transfer rate	54 Mbit/s	54 Mbit/s
Frequency bandKnown for one	2.4, 5 GHz	Unknown — not stated by the source
Cabling technology	10/100Base-T(X)	10/100Base-T(X)
Channels quantityKnown for one	13 channels	Unknown — not stated by the source
Power2 differ
Power requirementsDiffers	5V DC, 2.5A	12V DC
Output power descriptionDiffers	16 dBm	19dBm
Designidentical
LED indicatorsKnown for one	Power	Unknown — not stated by the source
Performanceidentical
Minimum system requirements	CD-ROM Drive Internet Explorer 4.0	CD-ROM Drive Internet Explorer 4.0
Compatible operating systemsKnown for one	Unknown — not stated by the source	Windows 2000/XP
Certificates1 differ
CertificationDiffers	FCC	FCC, CE, Wi-Fi
Weight & dimensions1 differ
Dimensions (WxDxH)Differs	186 x 175 x 48 mm	140 x 33 x 140 mm
Weight	400 g	400 g
Other features3 differ
Compliance industry standardsDiffers	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.3, IEEE 802.3u	IEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE 802.3u
Networking featuresDiffers	WLAN, Ethernet LAN	Ethernet LAN, WLAN
I/O portsDiffers	1x 10/100 Ethernet (RJ-45)	1x 10/100 Ethernet (RJ-45) 1x Power
Operational conditions2 differ
Operating relative humidity (H-H)	10 - 85%	10 - 85%
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Storage temperature (T-T)Differs	-20 - 70 °C	0 - 70 °C
Storage relative humidity (H-H)Differs	5 - 90%	10 - 90%
Securityidentical
MAC address filteringKnown for one	Unknown — not stated by the source	Yes
Service Set Identifier (SSID) featuresKnown for one	Unknown — not stated by the source	SSID broadcast on/off

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
