Product comparison · 2 wireless access points

Dell PowerConnect W-AP103H 1000 Mbit/s White Power over Ethernet (PoE) vs Dell PowerConnect W-AP205 1000 Mbit/s White Power over Ethernet (PoE)

32specifications compared
17differ
15identical
3known for one product only

Key differences

Ethernet LAN (RJ-45) ports
- PowerConnect W-AP103H 1000 Mbit/s White Power over Ethernet (PoE):2
- PowerConnect W-AP205 1000 Mbit/s White Power over Ethernet (PoE):1
Power consumption (typical)
- PowerConnect W-AP103H 1000 Mbit/s White Power over Ethernet (PoE):8.3 W
- PowerConnect W-AP205 1000 Mbit/s White Power over Ethernet (PoE):12.5 W
LED indicators
- PowerConnect W-AP103H 1000 Mbit/s White Power over Ethernet (PoE):Yes
- PowerConnect W-AP205 1000 Mbit/s White Power over Ethernet (PoE):LAN, Power, Status
Antennas quantity
- PowerConnect W-AP103H 1000 Mbit/s White Power over Ethernet (PoE):2
- PowerConnect W-AP205 1000 Mbit/s White Power over Ethernet (PoE):4
Antenna gain level (max)
- PowerConnect W-AP103H 1000 Mbit/s White Power over Ethernet (PoE):3.6 dBi
- PowerConnect W-AP205 1000 Mbit/s White Power over Ethernet (PoE):6 dBi
Certification
- PowerConnect W-AP103H 1000 Mbit/s White Power over Ethernet (PoE):cTUVus
- PowerConnect W-AP205 1000 Mbit/s White Power over Ethernet (PoE):FCC, CE
Width
- PowerConnect W-AP103H 1000 Mbit/s White Power over Ethernet (PoE):86 mm
- PowerConnect W-AP205 1000 Mbit/s White Power over Ethernet (PoE):150 mm
Depth
- PowerConnect W-AP103H 1000 Mbit/s White Power over Ethernet (PoE):30 mm
- PowerConnect W-AP205 1000 Mbit/s White Power over Ethernet (PoE):150 mm

Side by side

Differences highlightedShow differences only

Comparison of W-AP103H, W-AP205
35 specifications	A Dell PowerConnect W-AP103H 1000 Mbit/s White Power over Ethernet (PoE) Model W-AP103H View product	B Dell PowerConnect W-AP205 1000 Mbit/s White Power over Ethernet (PoE) Model W-AP205 View product
Features2 differ
2.4 GHz	Yes	Yes
5 GHz	Yes	Yes
Maximum data transfer rate	1000 Mbit/s	1000 Mbit/s
Wi-Fi data rate (max)Known for one	300 Mbit/s	Unknown — not stated by the source
Ethernet LAN data rates	10,100,1000 Mbit/s	10,100,1000 Mbit/s
Frequency band	2.4, 5 GHz	2.4, 5 GHz
Networking standardsDiffers	IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u	IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af
ModulationDiffers	16-QAM, 256-QAM, 64-QAM, BPSK, CCK, QPSK	16-QAM, 256-QAM, 64-QAM, BPSK, QPSK
Maximum data transfer rate (5 GHz)Known for one	Unknown — not stated by the source	867 Mbit/s
Ports & interfaces1 differ
Ethernet LAN (RJ-45) portsDiffers	2	1
DC-in jack	Yes	Yes
Power1 differ
Power over Ethernet (PoE)	Yes	Yes
Power consumption (typical)Differs	8.3 W	12.5 W
Power consumption (max)Known for one	9.4 W	Unknown — not stated by the source
Design1 differ
Product colour	White	White
Cable lock slot	Yes	Yes
Cable lock slot type	Kensington	Kensington
Reset button	Yes	Yes
LED indicatorsDiffers	Yes	LAN, Power, Status
Internal	No	No
Antenna2 differ
Antenna features	Integrated antenna	Integrated antenna
Antennas quantityDiffers	2	4
Antenna gain level (max)Differs	3.6 dBi	6 dBi
Certificates1 differ
CertificationDiffers	cTUVus	FCC, CE
Weight & dimensions4 differ
WidthDiffers	86 mm	150 mm
DepthDiffers	30 mm	150 mm
HeightDiffers	140 mm	41.5 mm
WeightDiffers	260 g	380 g
Packaging data4 differ
Package widthDiffers	143 mm	190 mm
Package depthDiffers	49 mm	187 mm
Package heightDiffers	168 mm	57 mm
Package weightDiffers	420 g	550 g
Operational conditions1 differ
Operating relative humidity (H-H)	5 - 95%	5 - 95%
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Storage temperature (T-T)Differs	40 - 70 °C	-40 - 70 °C

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
