Product comparison · 2 wired routers

Zyxel 2 Plus vs Zyxel 660H-T1 v3s

18specifications compared
9differ
9identical
20known for one product only

Key differences

Networking standards
- 2 Plus:IEEE 802.3
- 660H-T1 v3s:IEEE 802.1D
Ethernet LAN (RJ-45) ports
- 2 Plus:5
- 660H-T1 v3s:4
Product colour
- 2 Plus:Silver
- 660H-T1 v3s:Black
LED indicators
- 2 Plus:Yes
- 660H-T1 v3s:Status
Operating temperature (T-T)
- 2 Plus:0 - 50 °C
- 660H-T1 v3s:0 - 40 °C
Operating relative humidity (H-H)
- 2 Plus:20 - 95%
- 660H-T1 v3s:20 - 85%
Weight
- 2 Plus:304 g
- 660H-T1 v3s:280 g
Dimensions (WxDxH)
- 2 Plus:181 x 128 x 36 mm
- 660H-T1 v3s:180 x 127 x 37 mm

Side by side

Differences highlightedShow differences only

Comparison of 2 Plus, 660H-T1 v3s
38 specifications	A Zyxel 2 Plus View product	B Zyxel 660H-T1 v3s View product
Network1 differ
Networking standardsDiffers	IEEE 802.3	IEEE 802.1D
Ethernet interface type	Fast Ethernet	Fast Ethernet
Ethernet LAN	Yes	Yes
Cabling technology	10/100Base-T(X)	10/100Base-T(X)
Ethernet LAN data rates	10,100 Mbit/s	10,100 Mbit/s
ATM featuresKnown for one	Unknown — not stated by the source	RFC 1483/2684, RFC 2364 PPP AAL5, RFC 2516 PPP Ethernet, VC / LLC, ATM QoS UBR/CBR/VBR, I.610 OAM F4/F5, AIS, RDI OAM
DSL featuresidentical
ADSL2+Known for one	Unknown — not stated by the source	Yes
Downstream data rateKnown for one	Unknown — not stated by the source	24 Mbit/s
DSL specificationKnown for one	Unknown — not stated by the source	ANSI T1.413 Issue 2, ITU G.992.1 G.dmt, ITU G.992.2 G.lite, ITU G.994.1 G.hs, ITU ADSL2 G.992.3, G.992.4, ITU ADSL2+ G.992.5, RE ADSL
Management featuresidentical
Web-based management	Yes	Yes
Quality of Service (QoS) supportKnown for one	Unknown — not stated by the source	Yes
Reset buttonKnown for one	Unknown — not stated by the source	Yes
Ports & interfaces1 differ
Ethernet LAN (RJ-45) portsDiffers	5	4
DC-in jack	Yes	Yes
RS-232 portsKnown for one	1	Unknown — not stated by the source
Protocolsidentical
DHCP client	Yes	Yes
DHCP server	Yes	Yes
Management protocolsKnown for one	Unknown — not stated by the source	SUA/Multi-NAT, VPN (IPSec, PPTP), DNS proxy, Dynamic DNS, FTP/TFTP
DMZ supportKnown for one	Yes	Unknown — not stated by the source
Securityidentical
Firewall securityKnown for one	Unknown — not stated by the source	Stateful packet inspection (SPI) firewall, Denial of Service (DoS) protection, Distributed Denial of Service (DDoS) protection, IP filtering
MAC address filteringKnown for one	Yes	Unknown — not stated by the source
NAT functionalityKnown for one	Yes	Unknown — not stated by the source
Features1 differ
CertificationDiffers	EMC: FCC Part 15 Class B, CE-EMC Class B, C-Tick Class B, VCCI Class B	FCC, CE
SafetyKnown for one	CSA International, CE EN60950-1 (UL60950-1, CSA60950-1, EN60950-1, IEC60950-1)	Unknown — not stated by the source
Design2 differ
Product colourDiffers	Silver	Black
LED indicatorsDiffers	Yes	Status
Operational conditions2 differ
Operating temperature (T-T)Differs	0 - 50 °C	0 - 40 °C
Storage temperature (T-T)Known for one	Unknown — not stated by the source	-20 - 60 °C
Operating relative humidity (H-H)Differs	20 - 95%	20 - 85%
Storage relative humidity (H-H)Known for one	Unknown — not stated by the source	20 - 90%
Weight & dimensions1 differ
WeightDiffers	304 g	280 g
Packaging dataidentical
Package weightKnown for one	Unknown — not stated by the source	540 g
Other features1 differ
Power requirementsKnown for one	Unknown — not stated by the source	9 V DC, 0.6 A
Connectivity technology	Wired	Wired
Dimensions (WxDxH)Differs	181 x 128 x 36 mm	180 x 127 x 37 mm
Package dimensions (WxDxH)Known for one	Unknown — not stated by the source	280 x 165 x 51 mm
Remote administrationKnown for one	Unknown — not stated by the source	Telnet, FTP, Web, ICMP
WAN connectionidentical
Ethernet WANKnown for one	Yes	Unknown — not stated by the source

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
