Product comparison · 2 uninterruptible power supplies (upss)

APC Easy UPS On-Line, 1000VA/800W, Tower vs APC Easy UPS On-Line, 6kVA/6kW, Tower

39specifications compared
13differ
26identical
33known for one product only

Key differences

Output power capacity
- Easy UPS On-Line, 1000VA/800W, Tower:1 kVA
- Easy UPS On-Line, 6kVA/6kW, Tower:6 kVA
Output power
- Easy UPS On-Line, 1000VA/800W, Tower:800 W
- Easy UPS On-Line, 6kVA/6kW, Tower:6000 W
Input operation voltage (min)
- Easy UPS On-Line, 1000VA/800W, Tower:160 V
- Easy UPS On-Line, 6kVA/6kW, Tower:220 V
Input operation voltage (max)
- Easy UPS On-Line, 1000VA/800W, Tower:280 V
- Easy UPS On-Line, 6kVA/6kW, Tower:240 V
Battery recharge time
- Easy UPS On-Line, 1000VA/800W, Tower:4 h
- Easy UPS On-Line, 6kVA/6kW, Tower:3 h
Non-operating altitude
- Easy UPS On-Line, 1000VA/800W, Tower:0 - 14763.6 m
- Easy UPS On-Line, 6kVA/6kW, Tower:0 - 14763 m
Compliance certificates
- Easy UPS On-Line, 1000VA/800W, Tower:RoHS
- Easy UPS On-Line, 6kVA/6kW, Tower:RoHS, REACH, WEEE
Width
- Easy UPS On-Line, 1000VA/800W, Tower:145 mm
- Easy UPS On-Line, 6kVA/6kW, Tower:190 mm

Side by side

Differences highlightedShow differences only

Comparison of SRVPM1KIL, SRVPM6KIL
72 specifications	A APC Easy UPS On-Line, 1000VA/800W, Tower Model SRVPM1KIL View product	B APC Easy UPS On-Line, 6kVA/6kW, Tower Model SRVPM6KIL View product
Features5 differ
UPS topology	Double-conversion (Online)	Double-conversion (Online)
Output power capacityDiffers	1 kVA	6 kVA
Output powerDiffers	800 W	6000 W
Waveform	Sine	Sine
Input operation voltage (min)Differs	160 V	220 V
Input operation voltage (max)Differs	280 V	240 V
Input frequency	40/70 Hz	40/70 Hz
Output operation voltage (min)	220 V	220 V
Output operation voltage (max)	240 V	240 V
Surge energy rating	600 J	600 J
Number of input phasesKnown for one	Unknown — not stated by the source	1
Number of output phasesKnown for one	Unknown — not stated by the source	1
Single-phase input voltage supportedKnown for one	Unknown — not stated by the source	230 V
Crest factor	3:1	3:1
ECO mode	Yes	Yes
Emergency Power Off (EPO)Known for one	Unknown — not stated by the source	Yes
Audible alarm(s)	Yes	Yes
Audible alarm modesDiffers	Alarm when on battery, Low battery alarm, Overload alarm	Low battery alarm, Overload alarm
Auto-restart	Yes	Yes
Output voltage Total Harmonic Distortion (THD)Known for one	3%	Unknown — not stated by the source
Ports & interfacesidentical
USB port	Yes	Yes
Serial ports quantity	1	1
SmartSlot	Yes	Yes
AC outlet typesKnown for one	C13 coupler	Unknown — not stated by the source
Power plugKnown for one	C14 coupler	Unknown — not stated by the source
AC outlets quantityKnown for one	3 AC outlet(s)	Unknown — not stated by the source
USB 2.0 ports quantityKnown for one	1	Unknown — not stated by the source
Serial interfaceKnown for one	Yes	Unknown — not stated by the source
Serial interface typeKnown for one	RS-232	Unknown — not stated by the source
Battery1 differ
Battery recharge timeDiffers	4 h	3 h
Automatic battery test	Yes	Yes
Battery technologyKnown for one	Sealed Lead Acid (VRLA)	Unknown — not stated by the source
Battery weightKnown for one	10.6 kg	Unknown — not stated by the source
Designidentical
Form factor	Tower	Tower
Product colour	Black	Black
Display type	LCD	LCD
LED indicators	Yes	Yes
Operational conditions1 differ
Operating temperature (T-T)	0 - 40 °C	0 - 40 °C
Operating relative humidity (H-H)	0 - 95%	0 - 95%
Storage relative humidity (H-H)	0 - 95%	0 - 95%
Operating altitude	0 - 3000 m	0 - 3000 m
Non-operating altitudeDiffers	0 - 14763.6 m	0 - 14763 m
Storage temperature (T-T)Known for one	-20 - 50 °C	Unknown — not stated by the source
Packaging contentidentical
Cables included	USB cable	USB cable
Manual	Yes	Yes
Certificates2 differ
Compliance certificatesDiffers	RoHS	RoHS, REACH, WEEE
Waste Electrical and Electronic Equipment (WEEE) complianceKnown for one	Unknown — not stated by the source	Yes
CertificationDiffers	CE, IEC 62040-1-1, IEC 62040-1-2 REACH	CE; UKCA; EAC
Technical detailsidentical
Packaging recycled materialsKnown for one	Unknown — not stated by the source	Recycled cardboard
Preferred mounting positionKnown for one	Unknown — not stated by the source	no preference
Packaging without single use plasticKnown for one	Unknown — not stated by the source	No
Sustainable packagingKnown for one	Unknown — not stated by the source	No
Take-back systemKnown for one	Unknown — not stated by the source	No
Weight & dimensions4 differ
WidthDiffers	145 mm	190 mm
DepthDiffers	288 mm	374 mm
HeightDiffers	223 mm	336 mm
WeightDiffers	9.3 kg	13 kg
Battery widthKnown for one	23.5 cm	Unknown — not stated by the source
Battery depthKnown for one	36.5 cm	Unknown — not stated by the source
Battery heightKnown for one	33 cm	Unknown — not stated by the source
Packaging dataidentical
Package widthKnown for one	Unknown — not stated by the source	290 mm
Package depthKnown for one	Unknown — not stated by the source	1247 mm
Package heightKnown for one	Unknown — not stated by the source	460 mm
Package weightKnown for one	Unknown — not stated by the source	16 kg
Logistics dataidentical
Customs product code (TARIC)Known for one	Unknown — not stated by the source	8504409590
Country of originKnown for one	Unknown — not stated by the source	China
Harmonized System (HS) codeKnown for one	85078000	Unknown — not stated by the source
Other featuresidentical
MountingKnown for one	Unknown — not stated by the source	front; vertical
Nominal input voltage	230 V	230 V
Nominal output voltage	230 V	230 V
Output connection typeKnown for one	Unknown — not stated by the source	hard wire 3-wire (1P + N + E) for 1 zone(s)
Output voltageKnown for one	Unknown — not stated by the source	230 V

A dash means the value is not stated by the source. Unknown values are never counted for or against a product, and there is no overall score.
